Eagle LE8060 BENCH LATHE for Sale

Name: Eagle LE8060 BENCH LATHE for Sale
Brand: EAGLE
SKU: 140923964
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Eagle Industries, Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not Normal

Max. Swing Diameter 600mm

Place of Origin Shandong, China

Brand Name EAGLE

Model Number eagle LE8060 BENCH LATHE for sale

Power(W) 7.5kw

Certification CE

After-sales Service Provided No overseas service provided

Specifications

eagle LE8060 BENCH LATHE for sale
1).Pass CE,Gost
2).Max. swing over bed 600mm
3).Distance between centers 1000/1500/2000mm

eagle LE8060 BENCH LATHE for sale

Feature:

Large plane, good looking
Hardened & PEISHAUER-ground gears.
Dynamically balanced main spindle.
Multiple choice, you can choose metric or inch system, right or left hand wheel, multiple voltages and frequencies, with or without "CE" protection system and rapid moving system.

specifications:

Model	Unit	LE8060×1000	LE8060×1500	LE8060×2000	Standard accessories
Max. swing over bed	mm	600			3-Jaw chuck(160mm)
Max. swing over cross slide	mm	360			Driving plate
Max. swing over gap	mm	730			Center & center sleeve
Effective length of gap	mm	260			Tool box with tools
Bed width	mm	330			Oil gun
Distance between centers	mm	1000	1500	2000	Change gears set
Spindle nose		ISO-C8 OR ISO-D8
Spindle bore	mm	80			Optional accessories
Taper of spindle bore		Metric 85mm			Steady plates
Number of spindle speed		15			Follow rest
Range of spindle speed	r/min	24~1600			4-jaw chuck(200mm)
Range of longitudinal feeds	mm/rev	0.072~4.038			Face plate
Range of cross feeds	mm/rev	0.036~2.019			Thread dial
Range of metric threads	mm	0.5~28			Longitudinal automatic trip
Range of inch threads	tpi	1~56			Live center
Diameter of tailstock sleeve	mm	65			Quick change toolpost
Taper of tailstock bore		MT5			Taper copy ruler
Travel of tailstock sleeve	mm	120			4-position longitudinal automatic trip
Power of motor	kw	7.5			4-position longitudinal automatic trip
N.W/G.W	kg	1800/2500	2010/2760	2250/3070
Overall dimensions (L×W×H)	mm	2420×1150×1800	2920×1150×1800	3460×1150×1801
Item NO.		115026	115027	115028
