Specific program-controlled column moving surface grinder

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

surface grinder
NC servo on transverse,NC servo on vertical, hydraulic transmission on longitudinal.

Model		Unit	GTC 6016	GTC 6022	GTC 8016	GTC 8022	GTC 8030
Table size		mm	610×1600	610×2200	810×1600	810×2200	810×3000
Max. grinding (Lon×Tran)		mm	610×1600	610×2200	810×1600	810×2200	810×3000
Max. grinding height		mm	790	790	790	790	790
Longitudinal moving speed of worktable		m/min	6~23	6~23	6~23	6~23	6~23
Vertocal wheel head rotating			+30°, +5°	+30°, +5°	+30°, +5°	+30°, +5°	+30°, +5°
Vertocal wheel head rotating			-30°, -5°	-30°, -5°	-30°, -5°	-30°, -5°	-30°, -5°
Wheelhead cross movement	Rapid speed	m/min	0.05~2	0.05~2	0.05~2	0.05~2	0.05~2
Wheelhead cross movement	Feed electro of handwheel	mm/gra	0.005	0.005	0.005	0.005	0.005
Wheelhead vertical movement	Rapid speed	m/min	0.05~2	0.05~2	0.05~2	0.05~2	0.05~2
Wheelhead vertical movement	Feed electro of handwheel	mm/gra	0.005	0.005	0.005	0.005	0.005
Gringding wheel	speed	rpm	1450	1450	1450	1450	1450
Gringding wheel	size (OD×W×ID)	mm	According to the technique request	According to the technique request	According to the technique request	According to the technique request	According to the technique request
Spindle Motor		kw	5.5	5.5	5.5	5.5	5.5
Max.loading capacity of worktable(with chuck)		kg	1230	1690	1630	2240	3060
Total power		kw	17	17	17	17	19
Height of machine (include the packing base)		mm	2920	2920	2920	2920	2920
Floor space (L×W)		mm	4700×3000	6000×3000	4700×3500	6000×3500	8200×3600
Weight		kg	8500	9500	10000	11500	14000
Item NO.			121501	121511	121521	121531	121541

NC surface grinder servo on transverse,NC servo on vertical, hydraulic transmission on longitudinal.

Standard equipment

Coolant tank

Wheel dresser base

Flange and wheel extractor

Srandard wheel

Balane arbor

Balane stand

Working lamp

Leveling wedge and foundation bolt

Hydraulic angle wheel dresser

PLC auto grinding controller

Optional equipment

Electro magnetic chuck
