Series PLC NC Column Moving Surface Grinder

Name: Series PLC NC Column Moving Surface Grinder
Brand: EAGLE
SKU: 140923742
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Surface Grinding Machine

CNC or Not:

CNC

Eagle Industries, Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Surface Grinding Machine

CNC or Not CNC

Place of Origin Shandong, China

Brand Name EAGLE

Model Number GNC 6016A ~GNC 8030A

Specifications

Series PLC NC column moving surface grinder

Model		Unit	GNC 6016A	GNC 6022A	GNC 8016A	GNC 8022A	GNC 8022C	GNC 8030A
Model		Unit	GNC 6016B	GNC 6022B	GNC 8016B	GNC 8022B	GNC 8022C	GNC 8030B
Table size		mm	610×1600	610×2200	810×1600	810×2200	810×2200	810×3600
Magnetic chuck size		mm	600×800×2	600×1000×2	800×800×2	800×1000×2	800×1000×2	800×1000×3
Max.distance from spindle center to table surface		mm	820	820	820	820	925	820
Longitudinal moving speed of worktable		m/min	5~25	5~25	5~25	5~25	5~25	5~25
Wheel head cross moving	Auto feed	mm/t	1~30	1~30	1~30	1~30	1~30	1~30
	Rapid speed	m/min	0.05	0.05	0.05	0.05	0.05	0.05
	Feed of handwheel	mm/div	0.005	0.005	0.005	0.005	0.005	0.005
Wheelhead vertica movement	Auto feed	mm/t	0.005~0.05	0.005~0.05	0.005~0.05	0.005~0.05	0.005~0.05	0.005~0.05
	Rapid speed	m/min	0.05~2	0.05~2	0.05~2	0.05~2	0.05~2	0.05~2
	Feed of handwheel	mm/div	0.005	0.005	0.005	0.005	0.005	0.005
Gringding wheel	speed	rpm	960	960	960	960	1450	960
Gringding wheel	size (OD×W×ID)	mm	500×75×305	500×75×305	500×75×305	500×75×305	450×75×203	500×75×305
Spindle Motor		kw	18.5	18.5	18.5	18.5	18.5	18.5
Max.loading capacity of worktable(with chuck)		kg	1230	1690	1630	2240	3000	3060
Total power		kw	28.5	28.5	28.5	28.5	29.6	31
Height of machine (include the packing base)		mm	2700	2700	2700	2700	2700	2700
Floor space (L×W)		mm	4700×3000	6000×3000	4700×3500	6000×3500	6000×3500	8200×3600
Weight		kg	8500	9500	10000	11500	13000	14000
Item NO.			121401	121411	121421	121431	121433	121441
Item NO.			121402	121412	121422	121432	121433	121442

GIC A mean:NC servo on transverse,NC servo on vertical, hydraulic transmission on longitudinal.

GIC B mean:NC servo motor is used on cross and ertial movement and 2axis (y/z) is linkage, controlled by cnc.ydraulic drove longitudinal movement

Standard equipment	Optional equipment:	Optional equipment only for B series:
Coolant tank	Electro magnetic chuck	frame wheel dresser
Wheel dresser base	Manual parallel wheel dresser	NC dividing head
Flange and wheel extractor	Coolant tank with magnetic separator	Hydraulic chuck
Srandard wheel		Hydraulic tailstock
Balane arbor
Balane stand
Working lamp
Leveling wedge and foundation bolt
PLC auto grinding controller
