Wheel Head Moving Surface Grinder
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Surface Grinding Machine
CNC or Not:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Surface Grinding Machine
CNC or Not
Normal
Place of Origin
Shandong, China
Brand Name
EAGLE
Model Number
GH3010~3210
Specifications
Wheel Head Moving Surface GrinderThe hydraulic system drive the worktable in crosswiss diretion.
The hydraulic system drive the worktable in crosswiss diretion. Both hydraulic and manual driver are available in the wheel head longitudinal motion. The vertical motion of the wheel head comes from quick autonmatic or manual driver. The bigger diameter of the wheel and the more power of motor achieve outstanding efficiency
| Wheel Head Moving Surface Grinder | ||||||
| Model | Unit | GH 3010/6 | GH 3010/10 | GH 3010/14 | GH 3210 | |
| worktable size (W×L) | mm | 300×1000 | 320×1000 | |||
| Magnetic chuck size | mm | 300×680×1 | 320×1000×1 | |||
| Max.distance from spindle center to table surface | mm | 600 | 1000 | 1400 | 600 | |
| Longitudinal moving speed of worktable | m/min | 3~27 | ||||
| T-slot number×wideth | mm | 3×18 | ||||
| Wheel head cross moving | Consecutive feed speed | m/min | 0.5~4.5 | |||
| Intermittent feed speed | mm/t | 3~30 | ||||
| Hand wheel feed | mm | |||||
| Vertical moving of wheel head | Rapid speed | mm/min | 400 | |||
| Hand wheel feed | mm/gra | 0.005 | ||||
| Wheel head motor | Power | kw | 7.5 | |||
| Rotation speed | rpm | 1440 | ||||
| Total power | kw | 11 | 11.2 | 11.2 | 11 | |
| Max.loading capacity of worktable(with chuck) | kg | 470 | 900 | 1170 | 500 | |
| Wheel size (OD×W×ID) | mm | 400×40×127 | ||||
| Machine dimension (L×W×H) | mm | 2860×1850×2030 | 2860×1850×2510 | 2860×1850×2930 | 2860×1870×2030 | |
| Item NO. | 126010 | 126011 | 126012 | 126013 | ||
| Standard equipment | Optional accessories |
| Wheel dresser base | wheel balancing stand |
| Flange and wheel extractor | |
| Srandard wheel | |
| Balane arbor | |
| Balane stand | |
| Scrubbing brush | |
| Magnetic chuck |
