Lurking Pull Type AGV-automated Guided Vehicle, Patent Pending
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Specifications
powerful system integration and the automatization logistics solution ability for AGVLurking Pull Type AGV, one-way driving, the relatively low vehicle body can make lurk under the skip car to hang the buckle or trip the buckle automatically; the traction device in the tail can hang several skip cars. It reads the landmark instruct through magnetic strip navigation and can set the stops for the sites according to it. This vehicle is mostly used for the logistics distribution in industries like automobile and household appliances.
AGV Driving Route Map Case
Technical parameters
| Overall Dimension | L1400*W350*H280(mm) |
| Moving Way | Magnetic stripe navigation |
| Moving Directions | Going ahead,turning to the left and the right, bifurcating |
| Means of Communication | Wireless Local Area Network |
| Driving Mode | Differential driving |
| Driving Power | DC24V ,DC48V |
| Carrying Capacity | 300Kg ,500Kg,750kg,1000kg (or custom made) |
| Model | Lurking AGV |
| Carrying Capacity | 30-45m/minute(or custom made) |
| Turning Radius | The minimum could be 300mm(the magnetic stripe path lays the radius) |
| Navigation Accuracy | ±10mm |
| Manner of Working | 24hours |
| Climbing Capacity | 3-5° |
| Stop Precision | ±10mm |
| Charge Methods | Manual Charging /Automatic Charging |
| Safety Induction Scope | ≤3m,adjustable,the urgent braking length is less than 20mm |
| Alarm Form | Acousto-optic Alarm |
| Storage Battery | Maintenance free charging, continuous discharge times are more than 300. |
| Safety Protection | The front obstacle detects the sensor + machinery anticollision mechanism double protection |
| Designed Life | More than 10 years |
AGV Frame diagram
Application schematic diagram
