Help CenterMulti-sites Saddled AGV
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Small Saddled Tray Type AGV-automated Guided VehicleNegotiableMOQ: 1 -
One-way Saddled Type AGV-automated Guided VehicleNegotiableMOQ: 1 Set
-
Standard One-way Carrying-automated Guided VehicleNegotiableMOQ: 1 Set
-
Single Drive Two-Way Saddled AGV-automated Guided VehicleNegotiableMOQ: 1
-
Super-low Lurking AGV-automated Guided Vehicle, Patent PendingNegotiableMOQ: 1
Place of Origin
Guangdong, China
Specifications
on the vehicle body. point-to-multipoint material handling through magnetic stripe navigationMulti-sites saddled AGV, it places the work bin on the vehicle body. It can conduct point-to-multipoint material handling through magnetic stripe navigation. It can also automatically shift to the site selectively through calling the system. This vehicle is suitable for the production system which is used for frequent transportation and long period material supply.
AGV Driving Route Map Case
Technical parameters
| Overall Dimension | L1400*W600*H350(mm) |
| Moving Way | Magnetic stripe navigation |
| Moving Directions | Can be defined line, many sites parked function,Going ahead, turning to the left and the right, bifurcating |
| Means of Communication | Wireless Local Area Network |
| Driving Mode | Differential driving |
| Driving Power | DC24V |
| Carrying Capacity | 150Kg (or custom made) |
| Model | Multi-sites saddled AGV |
| Carrying Capacity | 30-45m/minute(or custom made) |
| Turning Radius | The minimum could be 800mm(the magnetic stripe path lays the radius) |
| Navigation Accuracy | ±10mm |
| Manner of Working | 24hours |
| Climbing Capacity | 3-5° |
| Stop Precision | ±10mm |
| Charge Methods | Manual Charging /Automatic Charging |
| Safety Induction Scope | ≤3m,adjustable,the urgent braking length is less than 20mm |
| Alarm Form | Acousto-optic Alarm |
| Storage Battery | Maintenance free charging, continuous discharge times are more than 300. |
| Safety Protection | The front obstacle detects the sensor + machinery anticollision mechanism double protection |
| Designed Life | More than 10 years |
AGV Frame diagram
Application schematic diagram
