High Efficient PY Series Spring Cone Crusher

High Efficient PY Series Spring Cone Crusher thumbnail-1
High Efficient PY Series Spring Cone Crusher thumbnail-2
High Efficient PY Series Spring Cone Crusher thumbnail-3
High Efficient PY Series Spring Cone Crusher thumbnail-4
High Efficient PY Series Spring Cone Crusher thumbnail-5
High Efficient PY Series Spring Cone Crusher thumbnail-6
High Efficient PY Series Spring Cone Crusher photo-1
High Efficient PY Series Spring Cone Crusher photo-2
High Efficient PY Series Spring Cone Crusher photo-3
High Efficient PY Series Spring Cone Crusher photo-4
High Efficient PY Series Spring Cone Crusher photo-5
High Efficient PY Series Spring Cone Crusher photo-6
US$ 250,000 - 270,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Cone Crusher
Application:
Mining
Contact Supplier Request Quote Chat Now
Changzhou Machinery & Equipment Imp.&Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or depend on clients
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Cone Crusher
Application Mining
Motor Type AC Motor
Power(W) 260kw
Capacity(t/h) 200-580
Place of Origin Jiangsu, China
Brand Name AMEC
Model Number PYB2200
Dimension(L*W*H) 2790x1848x2844mm
Weight 80t
Certification ISO9001:2008
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

   Spring cone crusher is applied to process above medium hardness ore stone and rock. Its spring insurance system is overload protection to protect machine from damage of metal, grease and water seal are adopted, segregating stone powder and grease to guarantee stable working performance. This type of crushing chamber depends upon the purpose of mineral . The standard type (PYB) is applied to medium crushing, the medium type is applied to medium or fine crushing and the short head type is applied to hyper fine crushing. Spring cone crusher is widely applied in metallurgy, construction, white fuel, transportation, chemical engineering and construction material to process above medium hardness ore stone and rock, it has many advantages like reliable structure, high capacity, easy to adjust, low cost, and so on.

Raw Materials:
granite, marble, basalt, iron ore, cobble, shale, bluestone, coal, cobblestone, construction material
Application:
metallurgy, construction, white fuel, transportation, chemical engineering, construction material

Advantages of Cone Crusher
1.  Increasing or reducing the number of spacer to adjust chew clearance and suspension point height. Adding spacer could change the position of cone lining and principal axis to adjust the gap.
2.  Material is in the gap of cones to get squeezed, curved and sheared to make process easier and low energy consumption.
3.  Overload protection could lengthen service life of machine.
4.  Higher speed of operation, even size of final product, cube shape of product, high capacity.



Working Principle of Cone Crusher

    Spring Cone Crusher crushes materials by the working surface between the movable cone and fixed cone, so it is more advanced and efficiency than Jaw Crusher. The movable cone is supported by spherical bearing and fixed on an hanging erect shaft which is set in the eccentric sleeve, and the sleeve is set on the stopping and pushing bearing. The movable cone and erect shaft are driven by the eccentric shaft sleeve together. The eccentric shaft sleeve is driven by horizontal shaft and fimbriated gear, and the wheel of the conveyor belt is driven by motor through v-belts. The lower part of vertical shaft is installed in the eccentric sleeve. When the eccentric sleeve rotates, there is a conical surface lined out by the shaft. When the movable cone comes near the fixed cone, rocks are grinded into pieces, when the cone leaves, pulverized materials is discharged from the discharge hole. The fixed cone can be ascended or descended by adjusting.

High Efficient PY Series Spring Cone Crusher

Specification and Technical Parameter of PY Series Cone Crusher:
Model Diameter of Bottom End of Conical Crushing Head(mm) Max Feeding Size(mm) Adjustable Range of Discharge Opening(mm) Capacity(t/h) Motor Power(kw) Rev.of Eccentric Shaft(r/min) Weight(t) Dimension (L×W×H)(mm)
PYB600 Φ600 75 12-15 20-40 8P-30 356 5 2234×1370×1675
PYD600 Φ600 35 3-13 12-23 8P-30 356 5.5 2234×1370×1675
PYB900 Φ900 115 15-50 50-90 8P-55 333 11.2 2692×1640×2350
PYZ900 Φ900 60 5-20 20-65 8P-55 333 11.2 2692×1640×2350
PYD900 Φ900 50 3-13 15-50 8P-55 333 11.3 2692×1640×2350
PYB1200 Φ1200 145 20-50 110-168 8P-110 300 24.7 2790×1878×2844
PYZ1200 Φ1200 100 8-25 42-135 8P-110 300 25 2790×1878×2844
PYD1200 Φ1200 50 3-15 18-105 8P-110 300 25.3 2790×1878×2844
PYB1750 Φ1750 215 25-50 280-480 8P-160 245 50.3 3910×2894×3809
PYZ1750 Φ1750 185 10-30 115-320 8P-160 245 50.3 3910×2894×3809
PYD1750 Φ1750 85 5-13 75-230 8P-160 245 50.2 3910×2894×3809
PYB2200 Φ2200 300 30-60 590-1000 8P-(260-280) 220 80 4622×3302×4470
PYZ2200 Φ2200 230 10-30 200-580 8P-(260-280) 220 80 4622×3302×4470
PYD2200 Φ2200 100 5-15 120-340 8P-(260-280) 220 81.4 4622×3302×4470






High Efficient PY Series Spring Cone CrusherHigh Efficient PY Series Spring Cone CrusherHigh Efficient PY Series Spring Cone CrusherHigh Efficient PY Series Spring Cone CrusherHigh Efficient PY Series Spring Cone CrusherHigh Efficient PY Series Spring Cone CrusherHigh Efficient PY Series Spring Cone CrusherHigh Efficient PY Series Spring Cone Crusher
Packaging & Shipping

Nude packing for the main machine

Wooden case for the power motor and spare parts



Our Services

       We have office oversea we can easy to privide the csutomer about befroe sales service, machine quality control service ,technical support  and after service.

Company Information



      Changzhou Machinery and Equipment Import and Export Co., Ltd. (AMECCO) ()was founded in 1983. Taking advantage of the ownership of our six manufacturing subsidiary companies, we share our benefits in production and technology with our clients while we focus on the import and export of commodities and service. Strict quality control system, timely delivery and customer-oriented service make us have established trade relations with clients in more than 70 countries and regions.



Our main scope of our business:

Machinery and Equipment:

Power machinery, agricultural machinery, garden machinery, construction machinery, mining machine,machine tools and complete equipment

Power Transmission Parts

Chains, sprockets, taper bushes, gears and shafts



OEM components:

Machined, forged, cast, punched and welded workpiece

Micro Motors

Step motors, DC brushed & brushless motors, AC motors for aircon and paper shredder

Automobile Accessories

Auto lens and lamps, mirrors, motors and mechanical parts



Keeping the customers satisfied has been our strong wish. Please contact us for more information. We welcome your orders.
