High-Efficiency Symons Cone Crusher

High-Efficiency Symons Cone Crusher thumbnail-1
High-Efficiency Symons Cone Crusher thumbnail-2
High-Efficiency Symons Cone Crusher thumbnail-3
High-Efficiency Symons Cone Crusher thumbnail-4
High-Efficiency Symons Cone Crusher thumbnail-5
High-Efficiency Symons Cone Crusher photo-1
High-Efficiency Symons Cone Crusher photo-2
High-Efficiency Symons Cone Crusher photo-3
High-Efficiency Symons Cone Crusher photo-4
High-Efficiency Symons Cone Crusher photo-5
US$ 45,000 - 47,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Cone Crusher
Application:
Mining
Contact Supplier Request Quote Chat Now
Changzhou Machinery & Equipment Imp.&Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or depend on clients
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Cone Crusher
Application Mining
Motor Type AC Motor
Power(W) 75kw
Capacity(t/h) 45-163
Place of Origin Jiangsu, China
Brand Name AMEC
Model Number WKS90-B(3ft)
Dimension(L*W*H) 2656x1746x2241mm
Weight 15.5t
Certification ISO9001:2008
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

    WKS series cone crusher is a improved machine of PY series cone crusher. It’s applied in above medium hardness all kinds of ore and rock. Compared with PY series cone crusher, it has reliable structure, high efficiency, easy adjustment, low cost and many other advanrages. It’s applied in metallurgy, construction, white fuel, traffic, chemical engineering, construction material to process above medium hardness all kinds of ore and rock, it’s the best choice for large scale stone plant and ore crushing.

Raw Materials:
granite, marble, basalt, iron ore, cobble, shale, bluestone, coal, cobblestone, construction waste
Application:
metallurgy, construction, white fuel, transportation, chemical engineering, construction material

Advantages of WKS Cone  Crusher
1.Lamination crushing has a great performance on high hardness material, even and good final product shape, high capacity.
2.   Unique dry oil seal can protect machine from dust, reliable seal, Replacement cycle and service life of parts are lengthened.
3.   Spring system is overload protection to protect machine from metel damage.
4.   More material is allowed to be taken into machine, and discharge volume is increased.



Working Principle of WKS Cone Crusher

    When working, the motor will drive the eccentric shaft to move through the V-belt,big pulley, transmission shaft, small bevel gear, big bevel gear, the cone crusher's eccentric shaft central line will revolve wit the eccentric shaft sleeve.Then the concave will be close then far away from the mantle surface, then the material will be circled around the fixed and mobile cone, impacted, pressed and then curved. After many times of repetition, material would be crushed into the desired size, then discharged from the lower part.

High-Efficiency Symons Cone Crusher

Specification and Technical Parameter of PY Series Cone Crusher:
Standard:
Model WKS 75-B WKS 160-B WKS 250-B WKS 350-B
Specs 3Ft 900mm 4 1/4Ft 1275mm 5 1/2Ft 1650mm 7Ft 2134mm
Cavity Type narrow medium wide narrow medium wide narrow medium wide narrow medium wide
The Smallest Discharge
(mm) 		9 13 25 13 16 25 16 22 38 19 25 38
Corresponding
Feeding Size		 (close)side(mm) 83 159 163 109 188 238 188 213 331 253 303 425
(open) (mm) 102 175 178 137 210 259 209 241 368 278 334 460
Capacity(t/h) 45-91 50-120 59-163 109-181 132-253 172-349 181-327 258-417 299-635 381-726 608-998 789-1270
Weight(t) 15 26.5 43.5 67.3
Motor Power(KW) 6P-75 6P-160 6P-250 6P-350
Dimension(mm) 2865×2000×2190 3300×2500×2940 4105×3280×3505 5110×4270×4350

Short Head:
Model WKS-75-D WKS-160-D WKS-250-D WKS-350-D
Specs 3Ft 914mm 4 1/4Ft 1295mm 5 1/2Ft 1676mm 7Ft 2134mm
Cavity Type narrow medium wide narrow medium wide narrow medium wide narrow medium wide
The Smallest Discharge
(mm) 		3 3 6 3 6 16 5 6 13 5 10 16
Corresponding
Feeding Size 		(close)side(mm) 13 33 51 19 54 98 35 54 117 51 95 152
(open)(mm)
40 60 76 64 89 133 70 89 133 105 133 203
Capacity(t/h) 27-90 30-100 31-110 36-163 82-163 109-227 90-209 136-281 190-336 190-408 354-508 454-599
Weight(t) 15 26.5 43.5 67.3
Motor Power(KW) 6P-75 6P-160 6P-250 6P-350
Dimension(mm) 2865×2000×2190 3300×2500×2940 4105×3280×3505 5110×4270×4350








High-Efficiency Symons Cone CrusherHigh-Efficiency Symons Cone CrusherHigh-Efficiency Symons Cone CrusherHigh-Efficiency Symons Cone CrusherHigh-Efficiency Symons Cone CrusherHigh-Efficiency Symons Cone CrusherHigh-Efficiency Symons Cone CrusherHigh-Efficiency Symons Cone Crusher
Packaging & Shipping

Nude packing for the main machine

Wooden case for the power motor and spare parts



Our Services

       We have office oversea we can easy to privide the csutomer about befroe sales service, machine quality control service ,technical support  and after service.

Company Information



      Changzhou Machinery and Equipment Import and Export Co., Ltd. (AMECCO) ()was founded in 1983. Taking advantage of the ownership of our six manufacturing subsidiary companies, we share our benefits in production and technology with our clients while we focus on the import and export of commodities and service. Strict quality control system, timely delivery and customer-oriented service make us have established trade relations with clients in more than 70 countries and regions.



Our main scope of our business:

Machinery and Equipment:

Power machinery, agricultural machinery, garden machinery, construction machinery, mining machine,machine tools and complete equipment

Power Transmission Parts

Chains, sprockets, taper bushes, gears and shafts



OEM components:

Machined, forged, cast, punched and welded workpiece

Micro Motors

Step motors, DC brushed & brushless motors, AC motors for aircon and paper shredder

Automobile Accessories

Auto lens and lamps, mirrors, motors and mechanical parts



Keeping the customers satisfied has been our strong wish. Please contact us for more information. We welcome your orders.
