Condition New
Type Wheel Tractor
By wheel 2WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 40.7kw
Certificate EPA
Brand Name JM
Model Number 354
After-sales Service Provided Overseas third-party support available

Specifications

Reliable YTO-550 Chinese Agricultural Tractors
with reasonable price;
excellent performance;
own high quality;
easy control

  Reliable YTO-550 Chinese Agricultural Tractor   is Equipped with wet disc brakes, ensuring desirable braking performance and high reliability.  YTO-550 Chinese Agricultural Tractor adopts the planetary end transmission and double action clutches.  YTO-550 Chinese Agricultural Tractor is applicable to paddy fields and dry farmlands. It adopts the engagement sleeve gear shifting and force and position combined regulation. It is large in wheel span and axle base, heavy in dead load, and desirable in chassis stability. Besides,  YTO-550 Chinese Agricultural Tractor is equipped with safety anti-toppling shelf for optional assemblage.






Model
YTO-550
Diesel engine
Model
YT4A2-22
Type
Four cylinder, vertical, water cooled, four stroke
Displacement (L)
4.15
Rated power / speed (Kw) / (r/min)
40.4 / 2200
Max. torque (N.m) / speed (r/min)
214 / 1650
Bore x stroke (mm)
105 x 120
Transmission
Gear shift, forward / backward
8 / 4
Speed range (Km/h), forward / backward
2.47-32.38 / 3.66-11.18
PTO power (Kw)
36.7
PTO rotation speed (r/min)
540 / 720 or 540/ 1000
Clutch
11-inch, dry, double action
Implement
Three-point linkage category
Rear three-point linkage I
Tilling depth control mode
Combined draft, position control and floating control
Lifting force (KN)
9
Options
Cab
Frame construction, streamlined shape, with fan; air conditioning system is optional.
Transmission with shuttle-type gear
4x2x2
Transmission with creeper gear
4x(2+1)x2
Luxury integral panel
All-in-one instrument panel, glass guard plate
Hydraulic output
1 or 2 group
Adjustment mode, rear wheel
Stepless adjustment
Dimensions, mass, drive
Drive type
4x2
Overall dimensions (LxWxH) (mm)
3910x1745x2565
Wheelbase (mm)
2127
Min. ground clearance (mm)
400
Min. operating mass (with safety stand) (Kg)
2180
Tyre spec. front / rear
6.50-16 / 13.6-28
Wheel tread, front / rear
1350,1450 / 1300, 1400, 1500, 1600
Steering
Full hydraulic
Brake
Disk type, mechanical




Reliable YTO-550 Chinese Agricultural Tractors

Reliable YTO-550 Chinese Agricultural Tractors





 Reliable YTO-550 Chinese Agricultural Tractors





Our products are reliable,if you have any questions, please don't hesitate to contact us.And if you play an larger order, we will give you a discount. We also hope to do more future business with you.
