RD304 Chinese Tractor Price

RD304 Chinese Tractor Price thumbnail-1
RD304 Chinese Tractor Price photo-1
US$ 3,000 - 150,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Hubei Fotma Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 22.1KW
Certificate CE
Brand Name JIANG DONG
Model Number RD304
After-sales Service Provided Overseas third-party support available

Specifications

RD304 Chinese Tractor Price
Convenient control
High quality with reasonable price
Best performance
Good after-sales service

RD304 Chinese Tractor Price



Specification RD304 Chinese Tractor Price :



Type

4×4

Max.Traction Force (kN)

8.6

Max. Lifting Force(610mm behind the hitch point) (kN)

≥4.96

Power of PTO Shaft(kW)

19.9

PTO Shaft Speed (r/min)

540/720

Engine

Brand:JIANG DONG

Model:JD2102/Y3100IT(optional)

Type:4 stroke,Vertical type,water-cooling,2/3 cylinder

Nominal Power (kW):22.1

Rated Speed (r/min):2400/2350

Bore×Stroke(mm):JD2102:102×105
Y3100IT:100×117(optional)

Rated fuel consumption rate(g/kW·h):≤244

Clutch

Double action

Gearbox

8F+8R

Overall Dimensions(L×W×H) (mm)

3350×1525×2050

Wheelbase (mm)

1775

Front Wheel Tread (mm)

1040/1160/1230

Rear Wheel Tread (mm)

960-1460

Min. Ground Clearance (mm)

315

Weight (Kg)

1435

Differential Lock

Yes

Hydraulic Steering

Yes

Hydraulic Output

Yes

Tyre

6.5-16/11.2-24

Speed Range (Km/h)

Forward /Reverse:1.81-27.52/1.68-25.63

ROPS or Cab

None

Optional

/

/

Front ballast

Rear ballast

ROPS/ROPS+Awning

6.5-16/9.5-24(paddy tyre)

Testing

Front wheel tread:1100mm

Rear wheel tread:1300mm

Loading Quantity (units)

with ROPS

8



Chery is a large modern enterprise integrating the R&D, manufacturing, sales and services of marine equipment, construction machinery, special vehicle, agricultural equipment and the powertrain assembly and key parts.



Other  Chery Chinese Tractor models we can supply:RD304 Chinese Tractor Price

                                                                        Chery RC904 Tractor RD304 Chinese Tractor Price

                                                          Chery  RK554 Tractor

Technical Features
Equipped with the domestically famous engine CHINA II featuring high quality, powerful dynamics, high reliability and high coefficient of torque reserve.
Transmission gears 8F+4R, optional reversing device 12F+12R or 8F+8R, optional creeper 16F+8R, featuring reasonable speed-matching, high working efficiency, and good fuel economy.
Shift sleeve adopted, featuring convenient, comfortable and reliable control.
Double-acting clutch adopted, featuring convenient control and reliable performance.





If you are interested in above tractor model or more details of other tractor models, please do not hesitate to contact us.
