Jinma354 35hp Agricultural Tractor

Jinma354 35hp Agricultural Tractor thumbnail-1
Jinma354 35hp Agricultural Tractor photo-1
US$ 3,000 - 15,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Hubei Fotma Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Other, Gear Drive, 4WD
Power(W) 25.7kw
Certificate EPA
Brand Name Jinma
Model Number Jinma 354
Place of Origin Jiangsu, China
After-sales Service Provided Overseas third-party support available

Specifications

Jinma354 35hp agricultural tractor
3 cylinder diesel engine
Easy to operate
high quality; low price
Good after-sale service

Jinma354 35hp agricultural tractor



Details of Jinma354 35hp agricultural tractor in chart





Specification
Tractor parameters
Model
JM354
Drive type
4WD
Overall dimensions( L*W*H )

3230*1435*1985
Wheel track(mm)
  front
1200
  rear
1150-1450
Wheel bass(mm)
1833.5
Ground clearance(mm)
292
Rated traction force(N)
8800
Construction mass(kg)
1800
Min.turning radius(m)
4.2
Engine
Model
3cylinder
Type
3cylinder engine,
 water cooled
Rated power(km/hp)
25.7/35
Rated speed(rpm)
2350
Drive system
Clutch
Dual-stage
Gear box
(4+1)*2
Main drive
one pair of spiral bevel gearing
Differential
Bevel gear
Differential lock
Jaw lock
Final transmission
Spur gear,
 external gearing
Traveling mechanism
Type
   front
7.5-16
   rear
11.2-24
Steering gear
Hydraulic(power) steering
Brake
Disc type
Working device
Hydraulic system
Lifting capacity at 610mm(N)
5800
3-point suspension
Category:1
Gear pump flow
20L/Min
P.T.O  shaft
Rotating speed(rpm)
540/720 or 540/1000
Spline size
6 @ 35 Rectangular spline



Jinma354 35hp agricultural tractorJinma354 35hp agricultural tractorJinma354 35hp agricultural tractor



If you want to know more information, please send e-mail to us.
