2WD Tractors

Specifications

2WD Tractors
High quality with reasonable price;
Low fuel consumption and noise;
Excellent performance;
Convenient control.

Model	YTO-500
Diesel engine
Model	YT4A2-22
Type	Four cylinder, vertical, water cooled, four stroke
Displacement (L)	4.15
Rated power / speed (Kw) / (r/min)	36.8 / 2200
Max. torque (N.m) / speed (r/min)	195 / 1650
Bore x stroke (mm)	105 x 120
Transmission
Gear shift, forward / backward	8 / 4
Speed range (Km/h), forward / backward	2.37-31.06 / 3.52-10.74
PTO power (Kw)	32.5
PTO rotation speed (r/min)	540 / 720 or 540/ 1000
Clutch	10-inch, dry, double action
Implement
Three-point linkage category	Rear three-point linkage I
Tilling depth control mode	Combined draft, position control and floating control
Lifting force (KN)	8.3
Options
Cab	Frame construction, streamlined shape, with fan; air conditioning system is optional.
Transmission with shuttle-type gear	4x2x2
Transmission with creeper gear	4x(2+1)x2
Luxury integral panel	All-in-one instrument panel, glass guard plate
Hydraulic output	1 or 2 group
Adjustment mode, rear wheel	Stepless adjustment
Dimensions, mass, drive
Drive type	4x2
Overall dimensions (LxWxH) (mm)	3910x1745x2545
Wheelbase (mm)	2063
Min. ground clearance (mm)	400
Min. operating mass (with safety stand) (Kg)	2130
Tyre spec. front / rear	6.00-16 / 12.4-28
Wheel tread, front / rear	1350,1450 / 1300, 1400, 1500, 1600
Steering	Full hydraulic
Brake	Disk type, mechanical
