YTO504 Best Chinese Tractor

FOB Price

US$ 3,000 - 15,000 / Unit

1 Unit(Min. Order)

Port Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Wheel Tractor
By wheel	4WD	Usage	Farm Tractor
Drive Type	Gear Drive	Power(W)	37.1kw
Certificate	CE	Brand Name	YTO
Model Number	504	Place of Origin	Henan, China
After-sales Service Provided	Overseas third-party support available

Packaging Details

iron crate or nude packing

Product Description

Specifications

YTO504 best chinese tractor;
High quality and reasonable price;
Excellent performance;
better sale service;
easy control.

YTO504 Best Chinese Tractor

The YTO-504 tractor is equipped with wet disc brakes, ensuring desirable braking performance and high reliability. It adopts the planetary end transmission and double action clutches. It is applicable to paddy fields and dry farmlands. It adopts the engagement sleeve gear shifting and force and position combined regulation. It is large in wheel span and axle base, heavy in dead load, and desirable in chassis stability. Besides, it is equipped with safety anti-toppling shelf for optional assemblage.

Robust performance
Adopt the Yuchai engine, which is of high dependability, with low noise, low exhaust gas.

Optimized design
the load device is optimized designed, with reasonable joint layout, dependable position limit function. What's more, the bucket has the automatically function, which can lessen labor intensity, improve the working efficiency.

Brake is safe and reliability
urgent brake and car-stopping brake are made in one, which makes the brake more safe and reliable.

Stability
central designed backhoe and wingspread support leg guarantees stability of deep digging and breaking.

Transmission performance is dependable
adopts the cut blocked construction machinery transmission shaft, which makes the dependability of power transmission high.

Pilot controlled operation is safe and comfortable
adopts the pilot controlled hydraulic system, which is more concrete and saves labor intensity.

Automatically leveling function
the bucket has the automatically leveling function, which saves working time and improves working efficiency.

Performance is stability
big wheel base makes good carrying capability and strong over capacity.

Specification for YTO504 Best Chinese Tractor

Model	YTO-504
Diesel engine
Model	YT4A2-22
Type	Four cylinder, vertical, water cooled, four stroke
Displacement (L)	4.15
Rated power / speed (Kw) / (r/min)	36.8 / 2200
Max. torque (N.m) / speed (r/min)	195 / 1650
Bore x stroke (mm)	105 x 120
Transmission
Gear shift, forward / backward	8 / 4
Speed range (Km/h), forward / backward	2.37-31.06 / 3.52-10.74
PTO power (Kw)	32.7
PTO rotation speed (r/min)	540 / 720 or 540/ 1000
Clutch	10-inch, dry, double action
Implement
Three-point linkage category	Rear three-point linkage I
Tilling depth control mode	Combined draft, position control and floating control
Lifting force (KN)	8.3
Options
Cab	Frame construction, streamlined shape, with fan; air conditioning system is optional.
Transmission with shuttle-type gear	4x2x2
Transmission with creeper gear	4x(2+1)x2
Luxury integral panel	All-in-one instrument panel, glass guard plate
Hydraulic output	1 or 2 group
Adjustment mode, rear wheel	Stepless adjustment
Dimensions, mass, drive
Drive type	4x4
Overall dimensions (LxWxH) (mm)	3910x1745x2545
Wheelbase (mm)	2063
Min. ground clearance (mm)	350
Min. operating mass (with safety stand) (Kg)	2326
Tyre spec. front / rear	8.3-20 / 12.4-28
Wheel tread, front / rear	1250 / 1300, 1400, 1500, 1600
Steering	Full hydraulic
Brake	Disk type, mechanical

Photo for YTO504 Tractor
