Home > Products > ZL08 Series Wheel Loader with CE > quality farm tractors made in china
quality farm tractors made in china
- 3000 Set / Sets per Month
- Qingdao
- T/T
Product Details
Condition: | New | Brand Name: | SWLTD | Model Number: | ZL08B |
Place of Origin: | Shandong, China | Type: | Front Loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 4480*1400*2200 | Rated Load: | 800kg | Certification: | CE BV ISO |
Warranty: | 1year or 1000 working hours | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
mini wheel loaderCE Certification
Rated load:800kg
Engine:Weichai,Xinchai,Changchai
Strong ablity to overcome obstace
1) CE Certification
2) Rated load:800kg ;
3) Engine:Weichai,Xinchai,Changchai ;
4) Strong ablity to overcome obstace :
Specifications of ZL08B Wheel Loader
1.0 Engine Details
(1) Model: Changcai L24
(2) Engine type: In-line arrangement, water-cooled, one-cycle diesel Engine
(3) Rated Power: 17KW (23.12 H.P.)
(4) Rated Speed: 2200 r/min (rpm)
(5) Fuel Consumption ratio in standard working condition: 269g/kw.h
2.0 Steering System
(1) Cycloid full hydraulic steering system: BZZ-80
(2) System Pressure: 10MPa
(3) Steering Cylinder: Φ76x Φ63x160
(4) Speed
(a) Forward shift (forward I): 7.19
(b) Forward shift (forward II):3.35
(c) Reverse shift (Reverse I):7.19
(d) Reverse shift (Reverse II): 3.35
3.0 Bucket
(1) Bucket Capacity: 0.4 m3
(2) Bucket width: 1300mm
(3) Bucket type: Heavy-duty bolt on teeth
(4) Max. Breakout Force: 22.5KN
(5) Rated Load: 800kg
(6) Operating Weight: 2000kg
4.0 Overall Dimentions:
(1) Overall Length (Bucket on ground position): 4480mm
(2) Overall Height
(a) Ground to Cab Top: 2200mm
(b) Ground to exhaust pipe: It is below from the top of cabin
(c) Dumping Height: 2300mm
(3) Overall Width: 1400mm
5.0 Operating Specifications
(1) Drive Means: Two-wheel drive
(2) Min Turning Radius: 3000mm
(3) Driving System: mechanical
(4) Dumping Reach at max height: 900mm
(5) Min Base to the ground: 220mm
(6) Time of raise: 4.5sec.
(7) Hydraulic cycle time: 8.5sec.
6.0 Brake System
(1) Service Brake: mechanical brake
(2) Parking Brake: Hand operated
7.0 Wheelbas
1620mm
8.0 Track
1160mm
