Mini Skid Steer Loader ZL08B With ce for Sale

Specifications

1)mini wheel loader
2)We are an ISO9001 registered company, all of loaders have CE certificate
3)versatility
4)ease of operation

Specifications of ZL08B Wheel Loader

1.0 Engine Details

(1) Model: Changcai L24

(2) Engine type: In-line arrangement, water-cooled, one-cycle diesel Engine

(3) Rated Power: 17KW (23.12 H.P.)

(4) Rated Speed: 2200 r/min (rpm)

(5) Fuel Consumption ratio in standard working condition: 269g/kw.h

2.0 Steering System

(1) Cycloid full hydraulic steering system: BZZ-80

(2) System Pressure: 10MPa

(3) Steering Cylinder: Φ76x Φ63x160

(4) Speed

(a) Forward shift (forward I): 7.19

(b) Forward shift (forward II):3.35

(c) Reverse shift (Reverse I):7.19

(d) Reverse shift (Reverse II): 3.35

3.0 Bucket

(1) Bucket Capacity: 0.4 m3

(2) Bucket width: 1300mm

(3) Bucket type: Heavy-duty bolt on teeth

(4) Max. Breakout Force: 22.5KN

(5) Rated Load: 800kg

(6) Operating Weight: 2000kg

4.0 Overall Dimentions:

(1) Overall Length (Bucket on ground position): 4480mm

(2) Overall Height

(a) Ground to Cab Top: 2200mm

(b) Ground to exhaust pipe: It is below from the top of cabin

(c) Dumping Height: 2300mm

(3) Overall Width: 1400mm

5.0 Operating Specifications

(1) Drive Means: Two-wheel drive

(2) Min Turning Radius: 3000mm

(3) Driving System: mechanical

(4) Dumping Reach at max height: 900mm

(5) Min Base to the ground: 220mm

(6) Time of raise: 4.5sec.

(7) Hydraulic cycle time: 8.5sec.

6.0 Brake System

(1) Service Brake: mechanical brake

(2) Parking Brake: Hand operated

7.0 Wheelbase: 1620mm

8.0 Track: 1160m
