SWLTD 800kg Mini Wheel Loaders
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
SWLTD
Model Number:
ZL08
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Brand Name
SWLTD
Model Number
ZL08
Place of Origin
Shandong, China
Type
Mini Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
4480mm*1400mm*2200mm
Rated Load
800KG
Certification
CE,BV
Warranty
1 year
Specifications
mini wheel loadersCE certificate
Engine: Changchai L24
Hydraulic pilot control
Various tools and quick hitch device
SHANDONG WEILI WORLD MACHINERY CO.,LTD
Features
1. The ZL08-I mini wheel loaders uses the branded DI diesel engine as power, so it has the advantages of easy start, less oil consumption, strong power and environmental protection.
2. Using the dedicated engineering axles, the machine can make improvement for integral mechanical gearboxes, dual steering cylinders and so on, and can facilitate the operation.
3. The mini wheel loaders uses the branded big-flow hydraulic pumps and steering gear. The hoisting arms, direction change and so on take less time and the work efficiency is greatly increased through its matching with the diesel engine.
4. With 24V battery (dual battery), the mini wheel loaders will have an easy start in winter.
5. Its branded and high-quality rubber tire is far better for long-time operations in various environments.
6. The mini wheel loaders employs the high-articulated structure (the distance between upper and lower hinge plates is short and the turning radius is small) to further stabilize the driving operation.
7. Featuring unique appearance, the cab of the mini wheel loaders has a large operating space and wide vision so the machine achieves much safer operation.
8. The mini iwheel loaders has anoverhauled cover that is easy for maintenance.
Main Technical Parameter of ZL08 | |
Item |
Parameter |
Rated load (kg) |
800 |
Bucket capacity (m3) |
0.4 |
Wheel tread (mm) |
1160 |
Wheel base (mm) |
1620 |
Min turning radius (mm) |
3000 |
Min ground clearance (mm) |
220 |
Dumping height (mm) |
2300 |
Corresponding dumping reach (mm) |
900 |
Lifting time (s) |
4.5 |
Hydraulic cycle time (s) |
9 |
Maximum excavating force (KN) |
21 |
Drive mode |
Rear Wheel Drive |
Machine weight (kg) |
2000 |
Overall dimensions (mm) (Length*width*height) |
4480*1400*2200 |
Engine model |
ChangchaiL22 |
Rated power of engine (kw) |
15.5 |
Rated speed of engine (rpm) |
2200 |
