JMC 4*2 Articulated Aerial Platform Truck
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Transmission Type | Manual | Condition | New | |
| Emission Standard | Euro 3 | Fuel Type | Diesel | |
| Dimensions (L x W x H) (mm) | 7300*2000*3100mm | Place of Origin | Hubei, China | |
| Brand Name | JMC | Model Number | CLW5050JGKZ3 |
Product Description
JMC 4*2 articulated aerial platform truck
Main technical parameters:
Item | Unit | Parameter | |
Product | / | JMC 4*2 articulated aerial platform truck | |
Gross weight | kg | 5475 | |
Curb weight | 5150 | ||
Overall dimensions | mm | 7300×2000×3100 | |
Wheelbase | 3360 | ||
Axle number | / | 2 | |
Axle-load | kg | 2315/3160 | |
Tire specification | 7.00-16LT | ||
Engine | Model | / | JX493ZLQ3 |
Displacement | ml | 2771 | |
Power | kw/hps | 85/115 | |
Working Platform | Max working height: 13-14m | ||
Max working radium: 5.2m | |||
Rated payload of the platform: 200kg | |||
Rated person number of the platform: 5 | |||
Degree of the overturn: 360°turning (left or right) | |||
Standing Legs: H model , 4pcs, controlled by hydraulic system | |||
Other options: can be equipped with 1T hook | |||
Remarks:
The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
Reference Picture:
