Specifications
JMC 4*2 articulated aerial bucket truck1>Max working height: 13-14M
2>Rated payload: 200kg
3>Engine power: 115hp
JMC 4*2 articulated aerial bucket truck
Main technical parameters:
Item | Unit | Parameter | |
Product | / | JMC 4*2 articulated aerial bucket truck | |
Gross weight | kg | 5475 | |
Curb weight | 5150 | ||
Overall dimensions | mm | 7300×2000×3100 | |
Wheelbase | 3360 | ||
Axle number | / | 2 | |
Axle-load | kg | 2315/3160 | |
Tire specification | 7.00-16LT | ||
Engine | Model | / | JX493ZLQ3 |
Displacement | ml | 2771 | |
Power | kw/hps | 85/115 | |
Working Platform | Max working height: 13-14m | ||
Max working radium: 5.2m | |||
Rated payload of the platform: 200kg | |||
Rated person number of the platform: 5 | |||
Degree of the overturn: 360°turning (left or right) | |||
Standing Legs: H model , 4pcs, controlled by hydraulic system | |||
Other options: can be equipped with 1T hook | |||
Remarks:
The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
Reference Picture:
