Home > Transportation > Car > Conventional Fuel Vehicles > 2 Seats Electric Passenger Car for Personnel Carrier , CE Approved

2 Seats Electric Passenger Car for Personnel Carrier , CE Approved

2 Seats Electric Passenger Car for Personnel Carrier , CE Approved thumbnail-1
2 Seats Electric Passenger Car for Personnel Carrier , CE Approved photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, passenger car
Fuel:
Electric
Gear Box:
Automatic
Contact Supplier Request Quote Chat Now
Suzhou Eagle Electric Vehicle Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, passenger car
Fuel Electric
Gear Box Automatic
Made In China
Steering Left
Drive RWD
Place of Origin Jiangsu, China
Model EG6023K

2 seats Electric passenger car for personnel carrier , CE approved

Product Description



Model EG6023K EG6023K01 EG6023K03
System 48V/4KW Sepex 48V/3KW Sepex 48V/3KW AC system
Unit Price (FOB Shanghai)(Based on FCL) US$3,866.00 US$3,588.00 US$4,076.00
Key Components
Battery 6xT875(145Ah@5hr rate) 6xT875(145Ah@5hr rate) 6xT875(145Ah@5hr rate)
Motor 3.8KW Chinese motor 3KW Chinese motor 3KW German motor
Controller Curtis 1268 (400A@2minutes) Curtis 1266 (275A@2minutes) Zapi ACE0 (280A@2minutes)
Performance
Passenger capacity 2 2 2
Range (loaded) based on flat road at a speed of 20km/h (km)* >60 >60 >75
Max. speed @12.76:1 gear ratio 32 25 32
Max. speed @10.17:1 gear ratio 40 32  --
Minimum turning radius (m) 3.6 3.6 3.6
Max. climbing ability (loaded)   @ 12.49:1 gear ratio 20% 20% 20%
Max. climbing ability (loaded)   @ 10.25:1 gear ratio 15% 15%  --
Max. movement after brake at speed of 20km/h ≤4m ≤4m ≤4m
Max. loading weight 270kgs 270kgs 270kgs
Net weight 560kgs 557kgs 560kgs
Dimensions
Overall dimensions (mm) 2680X1290X1900
Min. ground clearance (mm) 95
Wheelbase (mm) N/A
Front wheel tread (mm) N/A
Rear wheel tread (mm) N/A
Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration)
Body and Frame
Frame Welded steel framework with sand blasting+paint treatment
Body Fibreglass
Roof Fibreglass+steel frame
Windshield Laminated glass
2 point seat belt
Large Seats:
     1) backrest and cushion Rebond seat + artificial leather
     2) armrest Steel pipe
Rear kits Fibreglass box
Golf bag
Dashboard Forward/reverse switch, assembly switch (front light, turn signal switch, horn switch), wiper switch,  battery capacity indicator, ignition key, 4 cup holders
steering wheel in wood finish /
Floor Non-slipping rubber
Inner rear view mirror One piece per cart in the middle of the windshield
Side rear view mirror Two pieces per cart
Battery watering system,48V system without water supply tool
Manual Pump water supply tool (other water supply tools are available)
Rain cover PVC
Electric system
Lighting system and horn 2 headlights, 2 front turn signals, 2 lowly-positioned taillights (including brake light and turn signal ), 2 highly-possioned brake lights, with DC-DC converter (converting from 48V to 12V), horn.
Reversing alarm
Switch assembly Lights switch, horn switch, wiper switch
Wiper 12V
Ice box 12V DC, 6L
Charger China origin, input 110V-240V~50Hz-60Hz, output 48V, 25A
Steering and Suspension
Steering system Single-stage rack and pinion steering system, automatic rocker compensating function
Brake system Mechanical brake
4-wheel hydraulic brake + hand brake
4-wheel hydraulic brake, front disc brake, rear drum brake
Accelerator Stepless speed change
Suspension system Front and rear plate spring + vibration absorber
Driving mode Rear axle two stage deceleration, motor direct driving
Rear axle Integrated, Gear ratio 12.76:1
Integrated, Gear ratio 10.26:1
Wheel & Tyre 8*7 steel rim with wheel cap, 18*8.5-8 4PR tyre



Color

 2 seats Electric passenger car for personnel carrier , CE approved

Packaging & Shipping



Container loading qty Disassembled Assembled
Qty/20' / 2units
Qty/40' / 4units
Qty/40'HQ 8units 4units

 2 seats Electric passenger car for personnel carrier , CE approved2 seats Electric passenger car for personnel carrier , CE approved

Company Information

 2 seats Electric passenger car for personnel carrier , CE approved

Certifications

 2 seats Electric passenger car for personnel carrier , CE approved

After-Sales Service



All electric golf carts sold by us are quality guaranteed.

We provide 13 months warranty to our electric vehicles from the shipping date.
