Home > Transportation > Car > Conventional Fuel Vehicles > Electric Personal Carrier, 4 Seats, CE Approved

Electric Personal Carrier, 4 Seats, CE Approved

Electric Personal Carrier, 4 Seats, CE Approved thumbnail-1
Electric Personal Carrier, 4 Seats, CE Approved photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, passenger car
Fuel:
Electric
Gear Box:
Automatic
Contact Supplier Request Quote Chat Now
Suzhou Eagle Electric Vehicle Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, passenger car
Fuel Electric
Gear Box Automatic
Made In China
Steering Left
Drive RWD
Brand Name Eagle
Place of Origin Jiangsu, China
Model EG6043K

Electric personal carrier, 4 seats, CE approved

Product Description



Model EG6043K EG6043K01 EG6043K08
System 48V/4KW Series 48V/4KW Sepex 48V/5KW AC System
Key Components
Battery 8xT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate)
Motor 3.8KW Chinese motor  3.8KW Chinese motor  5KW Chinese Motor
Controller Curtis 1204 (275A@2minutes) Curtis 1268 (400A@2minutes) Zapi ACE2(400A@2minute)
Performance
Passenger capacity 4 4 4
Range (loaded) based on flat road at a speed of 20km/h (km)* >80 >80 >105
Max. speed @12.76:1 gear ratio 32 32 32
Max. speed @10.26:1 gear ratio / 40  --
Minimum turning radius (m) 4 4 4
Max. climbing ability (loaded)   @ 12.76:1 gear ratio 20% 20% 20%
Max. climbing ability (loaded)   @ 10.26:1 gear ratio 15% 15%  --
Max. movement after brake at speed of 20km/h ≤4m ≤4m ≤4m
Max. loading weight 450kgs 450kgs 450kgs
Net weight 730kgs 732kgs 740kgs
Dimensions
Overall dimensions (mm) 3060x1400x1900
Min. ground clearance (mm) 155
Wheelbase (mm) 2080
Front wheel tread (mm) 1210
Rear wheel tread (mm) 1160
Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration)
Body and Frame
Frame Welded steel framework with sand blasting+paint treatment
Body Fibreglass + Plastic
Roof Fibreglass
Windshield Laminated glass
3point seat belt 4pcs
Large Seats:
     1) backrest and cushion Sponge + artificial leather
     2) armrest Soft expanded plastic
Hand holder for front passenger 1pc hand holder fixed under the roof
Hand holder for rear passenger 2pcs, fixed in the back of front backrest
Rear storage box Fibreglass
Floor Bamboo + artificial leather
Inner rear view mirror One piece per cart in the middle of the windshield
Side rear view mirror Two pieces per cart
Battery watering system,48V system without water supply tool
Manual Pump water supply tool (other water supply tools are available)
Rain cover PVC
Overshadowing Curtain /
Emergency power-off Button /
Electric system
Lighting system and horn 2 headlights, 2 front turn signals, 2 rear turn signals and 2 rear brake lights, with DC-DC converter (converting from 48V to 12V), horn.
Dashboard forward/reverse switch, headlight indicator, turn signal indicator, ignition key, voltameter, ammeter, emergency switch; turn signal switch, headlight switch, windscreen wiper switch, horn button; Storage for miscellaneous items
Audio System Radio and MP3 receiver
CD player to replace MP3 receiver
Microphone Wired
Speaker 2pcs
Reversing alarm
Switch assembly Lights switch, horn switch, wiper switch
Wiper 12V
Solar panel 48V/125W
Charger China origin, input 110V-240V~50Hz-60Hz, output 48V, 25A
Steering and Suspension
Steering system Single-stage rack and pinion steering system, automatic rocker compensating function
Electric Power steering /
Brake system Four wheel hydraulic drum brake+hand brake
Four wheel hydraulic drum brake+foot parking brake
Front disc brake and rear drum brake, with vacuum booster
Accelerator Stepless speed change
Front suspension Independent suspension, helix spring + shock absorber
Rear suspension rear plate spring + shock absorber
Driving mode Rear axle two stage deceleration, motor direct driving
Rear axle Integrated, Gear ratio 12.76:1
Integrated, Gear ratio 10.26:1
Wheel & Tyre 225/55b12 6PR tire, 12X7 aluminum wheel
175/60 R13 tire,13*5J steel wheel
20.5*8-10 tire,6J-10 steel wheel with the cover
20.5*8-10 tire,10*6 aluminum wheel
225/55b12 6PR tire, 12X7 steel wheel



Color

 Electric personal carrier, 4 seats, CE approved

Packaging & Shipping



Container loading qty Disassembled Assembled
Qty/20' 2units 1unit
Qty/40' 6units 3units
Qty/40'HQ 6units 3units

 Electric personal carrier, 4 seats, CE approvedElectric personal carrier, 4 seats, CE approved

Company Information

 Electric personal carrier, 4 seats, CE approved

Certifications

 Electric personal carrier, 4 seats, CE approved

After-Sales Service



All electric golf carts sold by us are quality guaranteed.

We provide 13 months warranty to our electric vehicles from the shipping date.
