CRAWLER EXCAVATOR
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
TIMAC
Model Number:
EXCAVATOR 60E
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
TIMAC
Model Number
EXCAVATOR 60E
Condition
New
Moving Type
Crawler Excavator
Operating Weight
6100kg
Bucket capacity
0.22M3
Maximum Digging Height
6040mm
Maximum Digging Depth
3850mm
Machine Weight
6100kg
Max Digging Radius
6150mm
CRAWLER EXCAVATOR
| DESCRIPTION | SPECIFICATON | |
| MODEL | EXCAVATOR 60E | |
| Working weight | 6100kg | |
| Bucket capacity | 0.22M3 | |
| Track width | 400mm | |
| Transport dimension | 5900*2660*2025mm | |
| Overall dimension | Length of track on ground | 2000mm |
| Ground clearance of counter weight | 720mm | |
| Tail swing radius | 1650mm | |
| Total length | 5900mm | |
| Total height | 2660mm | |
| Total width | 2025mm | |
| Track gauge | 1600mm | |
| Min. ground clearance | 340mm | |
| Track width | 400mm | |
| Track height | 590mm | |
| Dozer | 2000*375mm | |
| Working range | Max. working radius | 6150mm |
| Max. working radius on the ground | 6110mm | |
| Max. digging depth | 3850mm | |
| Max. digging height | 6040mm | |
| Max. dump height | 4250 mm | |
| Min. swing radius | 2310mm | |
| Performance | Ground pressure | 37Kpa |
| Swing speed | 9.9r/min | |
| Travelling speed high/low | 4.3/2.3km/h | |
| Grade ability | 35° | |
| Noise inside the cab | ≤85db(A) | |
| Fuel tank | 120L | |
| Engine | Company | YANMAR 4TNV94L-FSN |
| Type | 4 cylinder, inline, turbocharged | |
| Rated horsepower | 39KW/2200rpm | |
| Bore-stroke | 94*110mm | |
| Displacement | 3.054L | |
| Min. fuel consumption | ≤235g/kw.h | |
| Max. torque and revolution | 206Nm/2400RPM | |
| Main hydraulic pump | Company | NACHI |
| Type | PVD-3B-56P-18G5-4191A | |
| Rated pressure | 21.6Mpa | |
| Max. delivery | 160L/min | |
| Pump type | plunger variable pump + gear pump | |
| Method of power adjustment | constant output regulation | |
| Swing motor | Company | KOREA JEIL |
| Type | JMF-29-01-VBR-RK-19 | |
| Rated pressure | 21.6Mpa | |
| Max. delivery | 28.87cc/rev | |
| Travel motor | Company | KOREA JEIL |
| Type | JMV-44/22-02-VBC-RJ-45 | |
| Rated pressure | 21.6Mpa | |
| Max. delivery | 55L/min | |
| The pressure of hydraulic control system | Working part | 21.6Mpa |
| Traveling part | 21.6Mpa | |
| Hydraulic oil tank | 80L | |
| Hydraulic oil filter | Double filter in the tank | |
| Swing system | Swing speed | 9.9RPM |
| Type | constant closed disc type brake with buffer function | |
| Chassis system | Track feature | Double grouser, hydraulic tension |
| Track rollers and carrier rollers | Floating sealing | |
| Quantity | 1 carrier roller and 5 track rollers each side. | |
| Brake type | Hydraulic brake | |
| Working equipment | Arm length | 3010mm |
| Rod length | 1610mm | |
| Bucket digging force | ≥27N | |
| Rod crowed force | ≥39KN | |
| Driving cab | Cab | Imported cab, SAE certificate |
| Air-conditioner | Jiangsu chuang dao | |
| Seat | Direction adjustment | |
| Instrument panel | hour meter, engine revolution, oil temperature, water temperature, oil pressure. | |
| Electric | Power | 24V |
| Company | XUZHOU KANG DA | |
| instrument | Battery | 1×12V×120Ah |
| Standard equipment | Engine | YANMAR |
| Hydraulic pump | NACHI | |
| Control valve | KOREA JEIL | |
| Swing motor | KOREA JEIL | |
| Travel motor | KOREA JEIL | |
| Cylinder | HENG LI | |
| Electrical Instrument | YONG QING | |
| Driving cab | Comfortable | |
| Seat | Comfortable | |
| Painting | Nippon Paint |
