Specifications
TM 11Y Hydraulic Guillotine ShearTM 11Y Hydraulic Guillotine Shear
Features:
1. All steel welded structure, vibrating treatment of ageing for removal of internal stress, with good rigidity and stability.
2. Integrated hydraulic transimission systems, with good reliability.
3. Triple support rolling guide to raikl to eliminate gaps of support and enhance shearing quality.
4. Mechanical rear stopper with manual fine turning and digital indication.
5. Clearance is between shearing blades adjusted by hand wheel to be quickly, accurate and convenient.
6. Rectangular blades with four cutting edges to prolon working life, adjustable shearing angle to reduce deformation of the sheet.
7. Upper blade holder has inward tiling structure to facilitate material feed in and also enhance accuracy of the work piece.
8. Function of shearing in sections, function of aligning with light.
9. Optional: rear material holding device( or for other choice)
Model |
Shearing thickness |
Shearing width |
No.of stroke |
Backgauge rang |
Shearing angle |
The depth of throat |
Motor power |
Overall dimensions |
mm |
mm |
1/min |
mm |
degree |
mm |
kw |
mm(LxWxH) |
|
4x2500 |
4 |
2500 |
25-45 |
600 |
0.5-1.5 |
100 |
5.5 |
3000x2000x1850 |
6x2500 |
6 |
2500 |
20-45 |
750 |
0.5-1.5 |
125 |
7.5 |
3030x2075x1920 |
6x3200 |
6 |
3200 |
16-45 |
750 |
0.5-1.5 |
125 |
7.5 |
3030x2075x1970 |
6x4000 |
6 |
4000 |
14-45 |
750 |
0.5-1.5 |
125 |
7.5 |
4530x2075x2080 |
6x5000 |
6 |
5000 |
11-40 |
750 |
0.5-1.5 |
125 |
7.5 |
5530x2075x2210 |
6x6000 |
6 |
6000 |
9-36 |
750 |
0.5-1.5 |
125 |
7.5 |
6530x2075x2520 |
7x7000 |
7 |
7000 |
7-28 |
750 |
0.5-1.5 |
125 |
7.5 |
7530x2075x2830 |
8x2500 |
8 |
2500 |
20-45 |
750 |
0.5-1.5 |
125 |
7.5 |
3040x2075x1920 |
8x3200 |
8 |
3200 |
16-45 |
750 |
0.5-1.5 |
125 |
7.5 |
3740x2075x1920 |
12x2500 |
12 |
2500 |
12-35 |
1000 |
0.5-2 |
125/ 300 |
15 |
3110x2575x2210 |
12x3200 |
12 |
3200 |
7-35 |
1000 |
0.5-2 |
125/ 300 |
15 |
3810x2575x2420 |
12x4000 |
12 |
4000 |
8-35 |
1000 |
0.5-2 |
125/ 300 |
30 |
4610x2575x2530 |
16x2500 |
16 |
2500 |
16-40 |
1000 |
0.5-2.5 |
125/ 300 |
22 |
3130x2655x2200 |
16x4000 |
16 |
4000 |
12-40 |
1000 |
0.5-2.5 |
125/ 300 |
30 |
4630x2655x2570 |
