16Ton Hydraulic C-frame Press / Single Column Hydraulic Press YC16T

Name: 16Ton Hydraulic C-frame Press / Single Column Hydraulic Press YC16T
Brand: TIMAC
SKU: 140797676
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

US$ 5,000 - 15,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Henan, China

Brand Name:

TIMAC

Model Number:

YC16T

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name TIMAC

Model Number YC16T

Condition New

Specifications

1. Hydraulic c-frame press;
2. Nominal force: 160KN;
3. Optional rectangular press head;
4. Down stroke limited switch;

Hydraulic C-frame Press

Features:

1. The Hydraulic C-frame Press machine is a kind of medium hydraulic press with multifuctions.

2. It suitable for the calibration of the parts like bearings and moulding materials, and for the arber of parts like bearings and sleeves.

3. It can complete the technology function of bending, marking and shelling of plate material parts, and the function of stretching of simple parts.

4. It can also be used to press powder and plastic products which the requirements are not strict.

Specifications		Unit		YC16T
Nominal force		KN		160
The max. working pressure of the fluid		Mpa		12.8
The max. distance between the under surface of the slipperand the surface of the working table		mm		500
The max. stroke of the slipper		mm		350
Downlink velocity of the slipper		mm/s		50
Return velocity of the slipper		mm/s		105
Throat depth		mm		280
Thre size of the working table		mm		600x500
The height of the working table to the surface of the floor		mm		710
The diameter for cutting hole		mm		100
The diameter of cylinder hole		mm		125
The diameter of the center of plunger bar( hole of cross handle)		mm		30
The depth of the center of plunger bar( hole of cross handle)		mm		60
The screw thread diameter of plunger bar		mm		60
Description of oil pump		Pressur equalization variable axial plunger pump
The power for motors		kw	4
The configuration size of the machine tool	Front, Rear	mm	1050
	Left, Right	mm	650
	The height above the floor	mm	2100
Total weight (approx)		T	1.5
