Hydraulic C-frame Press YC315T

Name: Hydraulic C-frame Press YC315T
Brand: TIMAC
SKU: 140797670
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

US$ 5,000 - 15,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Henan, China

Brand Name:

TIMAC

Model Number:

YC315T

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name TIMAC

Model Number YC315T

Condition New

Single-column Hydraulic Press Machine

Features:

1. The single-column hydraulic press machine is a kind of medium hydraulic press with multifuctions.

2. It suitable for the calibration of the parts like bearings and moulding materials, and for the arber of parts like bearings and sleeves.

3. It can complete the technology function of bending, marking and shelling of plate material parts, and the function of stretching of simple parts.

4. It can also be used to press powder and plastic products which the requirements are not strict.

Specifications		Unit		YC315T
Nominal force		KN		3150
The max. working pressure of the fluid		Mpa		24.6
The max. distance between the under surface of the slipperand the surface of the working table		mm		1100
The max. stroke of the slipper		mm		600
Downlink velocity of the slipper		mm/s		20
Return velocity of the slipper		mm/s		65
Throat depth		mm		400
Thre size of the working table		mm		750x900
The height of the working table to the surface of the floor		mm		700
The diameter for cutting hole		mm		220
The diameter of cylinder hole		mm		400
Description of oil pump		Pressur equalization variable axial plunger pump
The power for motors		kw	22
The configuration size of the machine tool	Front, Rear	mm	2100
	Left, Right	mm	1200
	The height above the floor	mm	3500
Total weight (approx)		T	18.5
