Pneumatic Forging Hammer (Air Hammer)

Pneumatic Forging Hammer (Air Hammer) thumbnail-1
Pneumatic Forging Hammer (Air Hammer) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
TIMAC
Model Number:
AH-15 AH-25 AH-40 AH-55 AH-75 AH-150
Contact Supplier Request Quote Chat Now
Zhengzhou Timeway Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name TIMAC
Model Number AH-15 AH-25 AH-40 AH-55 AH-75 AH-150
Condition New

Specifications

1. Pneumatic forging hammer, air hammer;
2. Drawing-out, upsetting, punching, chiseliry, ect;
3. Special oil pump is provided;

Pneumatic Forging Hammer (Air Hammer)



Applications:

This pneumatic forging hammer is widely used for general forging works, such as drawing-out, upsetting, punching, chiseling, forge, welding, bending and twisting. It is also used for forging in bolster dies.



Features:

1. Ready operation is economic and convenient.

2. Easy to operate, by manipulating the hand lever or foot-pedal, all operating functions—idle run, top setting, pressing down, single blow, light or full series blow can be obtained as desired.

3. A special oil-pump is provided for lubricating the cylinders. Prior to running, turn the hand-crank of the pump to get the cylinders being lubricated beforehand.



Specification

AH-15

AH-25

AH-40

AH-55

AH-75

AH-150

Weight of falling parts (kg)

15

25

40

55

75

150

Maximum hit energy(kj)

0.16

0.27

0.53

0.7

1

2.5

Hit number(min-1)

245

250

245

230

210

180

Heigh of working area (mm)

160

240

245

270

297

370

Tup axis to frame front (mm)

140

200

235

270

280

350

Forges

Square (mmxmm)

30×30

40×40

52×52

60×60

65×65

130×130

Round (mm)

Φ35

Φ48

Φ68

Φ75

Φ85

Φ145

Motor

Type

Y100L1-

4-B3

Y132S1-

6-B3

Y132M1-

6-B3

Y132M2-

6-B3

Y160M-

6-B3

Y180M-

4-B3

Power(kw)

2.2

3

4

5.5

7.5

18.5

Weight

Hammer(kg)

270

720

710

1150

2300

3260

Anvil block(kg)





420

600

950

1500

Overall Dimension(mm)

700×450

×980

1100×500

×1300

1200×600

×1500

1300×700

×1600

1480×800

×1853

2390×1085

×2150
