Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > Drilling/Milling Machine
Drilling/Milling Machine
US$ 800 - 4,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Brand Name:
TIMAC
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
CNC or Not
Normal
Brand Name
TIMAC
Model Number
D-30A, MD-30A, MD-30B, GHD-40, GHD-40A, GHM-40A, GHM-45B, GHM-50B
Specifications
Drilling/Milling MachineDrilling/Milling Machine
Belt or gear head type drilling machine, drilling milling machine
| Model | D-30A | MD-30A | MD-30B | GHD-40 | GHD-40A | GHM-40A | GHM-45B | GHM-50B |
| Max.Drilling capacity (mm) | 31.5 | 31.5 | 31.5 | 40 | 40 | 40 | 45 | 50 |
| Width of facing milling (mm) | / | 80 | 80 | / | / | 80 | 80 | 120 |
| Diameter of facing milling (mm) | / | 22 | 22 | / | / | 22 | 28 | 32 |
| Diameter of column (mm) | 115 | 115 | 115 | 115 | 115 | 115 | / | / |
| Spindle travel (mm) | 130 | 130 | 130 | 120 | 120 | 120 | 120 | 130 |
| Distance spindle axis to column generating line (mm) | 202 | 202 | 202 | 272.5 | 272.5 | 272.5 | 260 | 380 |
| Max.Distance spindle nose to table (mm) | 790 | 745 | 460 | / | 745 | 745 | 475 | 500 |
| Max.Distance spindle nose to base (mm) | 1245 | 1245 | / | 800 | 1200 | 1245 | / | / |
| Spindle taper | MT3 | MT3 | MT3 | MT4 | MT4 | MT4 | MT4 | MT5 |
| Spindle speeds range | 100-2150 | 100-2150 | 100-2150 | 95-1600 | 95-1600 | 95-1600 | 95-1600 | 60-2200 |
| Spindle speeds series (r/min) | 12 | 12 | 12 | 6 | 6 | 6 | 6 | 12 |
| Dimension of worktable surface | 570×470 | 585×190 | 730×210 or 820×240 | / | 540×470 | 585×190 | 730×210 or 820×240 | 900×320 |
| Table travel (mm) | 515 | 370×140×515 | 450×170 or 540×170 | / | 515 | 370×140×515 | 450×170 or 540×170 | 400×320 |
| Dimension of base (mm) | 690×520 | 690×520 | / | 690×520 | 635×460 | 690×520 | 605×558 | / |
| Overall height (mm) | 1810 | 1810 | 1100 | 1450 | 1760 | 1810 | 1050 | 2230 |
| Main motor (W) | 1100 or 1500 | 1100 or 1500 | 1100 or 1500 | 750 or 1100 | 750 or 1100 | 750 or 1100 | 750 or 1100 | 1500/2200 |
| G.W/N.W (kg) | 360/320 | 360/320 | 285/250 | 310/270 | 350/310 | 375/335 | 318/278 | 1700/1500 |
| Packing dimension (cm) | 86×78×191 | 86×78×191 | 86×74×116 or 97×77×116 | 75×73×146 | 72×74×191 | 72×74×191 | 86×74×116 or 97×77×116 | 142×132×280 |
