Auto-feeding Drilling/Milling Machine
US$ 900 - 2,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Brand Name:
TIMAC
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
CNC or Not
Normal
Brand Name
TIMAC
Model Number
TRAPANO-1, TRAPANO-2, TRAPANO-3, TRAPANO-4, TRAPANO-5
Specifications
Auto-feeding Drilling/Milling MachineAuto-feeding Drilling/Milling Machine
1. Auto-feeding
2. Precision and stable
3. Widely used drilling machine
| Model | TRAPANO-1 | TRAPANO-2 | TRAPANO-3 | TRAPANO-4 | TRAPANO-5 |
| Max.Drilling capacity (mm) | 40 | 40 | 40 | 40 | 45 |
| Width of facing milling (mm) | / | 80 | / | 80 | 80 |
| Diameter of facing milling (mm) | / | 22 | / | 22 | 28 |
| Diameter of column (mm) | 115 | 115 | 115 | 115 | / |
| Spindle travel (mm) | 110 | 110 | 110 | 110 | 110 |
| Distance spindle axis to column generating line (mm) | 261.5 | 261.5 | 261.5 | 261.5 | 260 |
| Max.Distance spindle nose to table (mm) | / | 450 | 745 | 745 | 475 |
| Max.Distance spindle nose to base (mm) | 800 | / | 1245 | 1245 | / |
| Spindle taper | MT4/R8 | MT4/R8 | MT4/R8 | MT4/R8 | MT4 |
| Spindle speeds range | 50-1250 | 50-1250 | 50-1250 | 50-1250 | 50-1250 |
| Spindle speeds series (r/min) | 6 | 6 | 6 | 6 | 6 |
| Spindle feeds (mm/r) | 0.12, 0.18, 0.25 | 0.12, 0.18, 0.25 | 0.12, 0.18, 0.25 | 0.12, 0.18, 0.25 | 0.12, 0.18, 0.25 |
| Dimension of worktable surface | / | 730×210 or 820×240 | 540×470 | 585×190 | 730×210 or 820×240 |
| Table travel (mm) | / | 450×170 or 540×170 | 515 | 370×140×515 | 450×170 or 540×170 |
| Dimension of base (mm) | 690×520 | 605×400 | 690×520 | 690×520 | 605×558 |
| Overall height (mm) | 1450 | 1100 | 1760 | 1810 | 1100 |
| Main motor (W) | 750 or 1100 | 750 or 1100 | 750 or 1100 | 750 or 1100 | 750 or 1100 |
| Coolant motor (W) | 40 | 40 | 40 | 40 | 40 |
| G.W/N.W (kg) | 360/320 | 370/330 | 390/350 | 390/350 | 385/345 |
| Packing dimension (cm) | 75×73×146 | 86×74×116 or 97×77×116 | 72×74×191 | 72×74×191 | 86×74×116 or 97×77×116 |
