Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > "1100mm Width of Bed" Heavy-duty Horizontal Lathe Machine

"1100mm Width of Bed" Heavy-duty Horizontal Lathe Machine

Name: "1100mm Width of Bed" Heavy-duty Horizontal Lathe Machine
Brand: TIMAC
SKU: 140796416
Availability: InStock

"1100mm Width of Bed" Heavy-duty Horizontal Lathe Machine thumbnail-1

"1100mm Width of Bed" Heavy-duty Horizontal Lathe Machine photo-1

US$ 6,000 - 99,999 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Contact Supplier Request Quote Chat Now

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China port.

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 1250/1600/2000mm

Place of Origin Henan, China

Brand Name TIMAC

Model Number AL-1250, AL-1600, AL-2000

Voltage As request

Power(W) 30kw

Certification CE, ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Heavy duty horizontal lathe;
2. Swing dia. 1250,1600,2000mm;
3. 16tons loading;
4. 1100mm bed width.

Specification	Unit	AL-1250	AL-1600	AL-2000
Swing over bed	mm	1250	1600	2000
Swing over cross slide	mm	900	1250	1650
Max. length of workpiece	mm	3000/4000/5000/6000/8000/10000/12000/14000/16000/18000
Max. turning length	mm	2800/3800/4800/5800/7800/9800/11800/13800/15800/17800
Width of bed	mm	1100	1100	1100
Spindle nose		A2-15	A2-15	A2-15
Spindle bore	mm	100	100	100
Taper hole of Spindle		Metric 140	Metric 140	Metric 140
Spindle speed(forward)	rpm	21kinds, 3.15~315	21kinds, 3.15~315	21kinds, 3.15~315
Spindle speed(reverse)	rpm	12kinds, 3.5~291	12kinds, 3.5~291	12kinds, 3.5~291
Longitudinal feed range	mm/r	56kinds, 0.1~12(0.004"~0.473")
Cross feed range	mm/r	56kinds, 0.05~6(0.002"~0.236")
Upper tool-post feed range	mm/r	0.025~3(0.001"~0.118")
Number and range of metric thread	mm	44kinds, 1~120	44kinds, 1~120	44kinds, 1~120
Number and range of inch thread	TPI	31kinds, 28~1/4	31kinds, 28~1/4	31kinds, 28~1/4
Number and range of module thread	mm	45kinds, 0.5~60	45kinds, 0.5~60	45kinds, 0.5~60
Number and range of diametrical pitch thread	DP	38kinds, 1/2~56	38kinds, 1/2~56	38kinds, 1/2~56
Rapid travel speed(longitudinal)	mm/min	3740	3740	3740
Rapid travel speed(transverse)	mm/min	1870	1870	1870
Rapid travel speed(top slide)	mm/min	935	935	935
Distance between spindle center-line and tool resting plane	mm	53	53	53
Section of tool shank	mm	50	50	50
Tool post swing range		±90°	±90°	±90°
Max. travel of top slide	mm	53	53	53
Max. travel of cross slide	mm	740(29")	850(33")	900(35")
Tool post travel per turn of the dials of top or cross slide	mm	0.05(0.002")	0.05(0.002")	0.05(0.002")
Diameter of tailstock quill	mm	260	260	260
Travel of tailstock quill	mm	300(12")	300(12")	300(12")
Taper hole of tailstock quill		metric 80	metric 80	metric 80
Main motor power	kw	30	30	30
Max. weight of workpiece	kg	16000 (optional: 20000)

Features:

1. This series heavy-duty lathe adopts 1100mm wide rectangular induction hardened and ground bed guide ways, so of excellent stability, high rigidity, and with maximum bearing of 16 tons between centers.

2. The main spindle is of precision roller bearings 3-point supporting structure. Saddle guide ways with Teflon belt coated. Rotating tailstock quill structure to minimize friction and heat generation.

3. These machines are suitable for various turning works, such as turning of external and internal cylindrical surfaces, end surfaces, and turning of metric or inch threads, modular threads and diametrical pitch threads, etc.

4. Motorized short taper turning could be done by the top slide independently, and long taper’s motorized turning could be done by top slide combined with longitudinal feed. Further more, these machines can also carry out drilling, trepanning and boring processes, etc.
