"16 tons load-bearing "Heavy Duty Horizontal Lathe Machine For Sale (AL-1250/AL-1600/AL-2000)
Features :
1. This heavy duty lathe adopts 1100mm wide rectangular induction hardened and ground bed guide ways , so of excellent stablity , high rigidity , and with maximum bearing of 16 tons between centers.
2. The main spindle is of precision roller bearings 3-point supporting structure. Saddle guide ways with Teflon belt coated coated . Rotating tailstock quil structure to minimize friction and heat generation .
3. These machines are suitable for various turning works , such as turning of external and internal cylindrical surfaces end faces , and turning of metric or inch threads , modular threads and diametrical pitch threads , ect..
4. Motorized short taper turning could be done by the top slide independently , and long taper's motorized turning could be done by top slide combined with longitudinal feed . Further more , these machines can also carry out drilling , trepanning and boringprocesses , ect..
Parameter :
Specification |
Unit |
AL-1250 |
AL-1600 |
AL-2000 |
Swing over bed |
mm |
1250 |
1600 |
2000 |
Swing over cross slide |
mm |
900 |
1250 |
1650 |
Max. length of workpiece |
mm |
3000/4000/5000/6000/8000/10000/12000/14000/16000/18000 |
||
Max. turning length |
mm |
2800/3800/4800/5800/7800/9800/11800/13800/15800/17800 |
||
Width of bed |
mm |
1100 |
||
Spindle nose |
|
A2-15 |
||
Spindle bore |
mm |
100 |
||
Taper hole of spindle |
|
metric 140 |
||
Spindle speeds (forward) |
rpm |
21 kinds, 3.15~315 |
||
Spindle speeds (reverse) |
rpm |
12 kinds, 3.5~291 |
||
Longitudinal feed range |
mm/r |
56 kinds, 0.1~12 (0.004"~0.473") |
||
Cross feed range |
mm/r |
56 kinds, 0.05~6 (0.002"~0.236") |
||
Upper tool-post range |
mm/r |
0.025~3 (0.001"~0.118") |
||
Number and range of metric thread |
mm |
44 kinds, 1~20 |
||
Number and range of inch thread |
TPI |
31 kinds, 28~1/4 |
||
Number and range of module thread |
mm |
45 kinds, 0.5~60 |
||
Number and range of diametrical pitch thread |
DP |
38 kinds, 1/2~56 |
||
Rapid travel speed (longitudinal) |
mm/min |
3740 |
||
Rapid travel speed (transverse) |
mm/min |
1870 |
||
Rapid travel speed (top slide) |
mm/min |
935 |
||
Distance between spindle center-line and tool resting plane |
mm |
53 |
||
Section of tool shank |
mm |
50 |
||
Tool post swing range |
|
±90º |
||
Max. travel of tool post |
mm |
300 |
||
Max. travel of cross slide |
mm |
740 (29") |
850 (33") |
900 (35") |
|
Tool post travel per turn of the dials of top or cross slide |
mm |
0.05 (0.002") |
||
Diameter of tailstock quil |
mm |
260 |
||
Travel of tailstock quil |
mm |
300 (12") |
||
Taper hole of tailstock quil |
|
Metric 80 |
||
Main motor power |
kw |
30 |
||
Max.weight of workpiece |
kg |
16000(optional: 20000) |
||
