CNC Horizontal Boring Milling Machine
- 150 Set / Sets per Month
- China port.
- T/T Credit Card PayPal
- CNC Milling Machines,Mini CNC Milling Machines,DIY CNC Milling Machines,Hobby CNC Milling,DIY milling
- Benchtop CNC Mill, desktop cnc mill, Compact CNC, educational cnc, prototype cnc, cnc for school, training cnc
- CNC Milling Machines,Mini CNC Milling Machines,DIY CNC Milling Machines,Hobby CNC Milling,DIY milling
- Small CNC Milling Machine for School, Hobbist,Prototype,DIY
- YORNEW Desktop CNC Lathe Machine, education cnc, vocation cnc, hobby cnc, diy cnc
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | TIMAC |
Model Number: | TXK-140 | Type: | Horizontal | CNC or Not: | CNC |
Voltage: | As Customers' Request | Power(W): | 26kw | Weight: | 24000kg |
Certification: | CE, ISO Standard | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1. FANUC control system2. FAGOR gratings for X/Y/Z axe
3. Table size 1400x1600mm
Features:
1. The machine is able to control X, Y, Z, W and B axes, which four of them can be linkage controlled simultaneously.
2. Spindle material is wear resistant alloy with a hardness of HRC55.
3. Headstock adopts shower type lubrication and cooling to ensure the thermal stability of spindle system.
4. The spindle transmission system is equipped with ZF double-speed reducer for effective heavy cutting function.
5. Strong hydraulic system to ensure reliable table locking.
6. FANUC control system is adopted for standard configuration.
7. Spindle can be extended by 500mm for increasing rigidity in machining deep holes, which is stable with long serve life.
8. Hydraulic system is used for balance of Y axis(headstock).
9. This machine is a machining center with automatic tool change system.
10. FAGOR gratings are equipped for X, Y, Z axes to form closed-loop control.
Specification | Unit | TXK-140 |
Table travel(X) | mm | 2000 |
Headstock travel(Y) | mm | 1700 |
Table travel(Z) | mm | 1800 |
Spindle travel(W) | mm | 500 |
Distance from spindle center line to table | mm | 0~1700 |
Distance from spindle nose to table center | mm | 85~2385 |
Table size | mm | 1400x1600 |
Min. indexing of table | ° | 0.001° |
Precision of table indexing | 10" | |
Max. turning torque of table | Kg f.m | 650 |
Max. loading of table | kg | 7000 |
Table T-slot(Number-WidthxSpace) | 7-22x200 | |
Spindle diameter | mm | φ110 |
Spindle speed range | rpm | 8~2500 |
Main motor torque(power) | Nm (kw) | 140(22/26) |
Torque(power) of X,Y,Z axis motors | Nm (kw) | 38(6) |
Torque(power) of W axis motor | Nm (kw) | 22(4) |
Torque(power) of table turning motor | Nm (kw) | 30(7) |
Range of feed rate | mm/min | 10~5000 |
Rapid feed of X,Y,Z | m/min | 10 |
Rapid of W axis | m/min | 4 |
Positioning accuracy(for the whole travel) | mm | 0.025 |
Re-positioning accuracy(X/Y/Z) | mm | ±0.005 |
Magazine capacity | 60 | |
Max. OD of tools | mm | φ125(full of tools); φ245(neighbor vacant) |
Max. length of tools | mm | 400 |
Max. weight of single tool | kg | 25 |
APC tool change time | s | 13 |
Min. input(X/Y/Z) | mm | 0.001 |
Overall dimensions(LxWxH) | mm | 6500x6100x3830(with chip conveyor) |
Net weight | kg | 24000 |
