Product Details
Condition: | New | Brand Name: | TIMAC | Model Number: | KTM-230A |
Type: | Vertical | CNC or Not: | CNC |
Product Description
Specifications
CNC Milling MachineSpecification | Unit | KTM-230A | ||
Table size | mm | 230x1067 | ||
T slots |
| 3x16 | ||
Table loading | kg | 200 | ||
X axis travel | mm | 550 | ||
Y axis travel | mm | 300 | ||
Z axis travel | mm | 127 | ||
X/Y/Z axis rapid feed | mm/min | 5000 | ||
X/Y/Z axis servo motor | kw | 1 | ||
Knee vertical travel | mm | 380 | ||
Ram travel | mm | 315 | ||
Distance from spindle to table | mm | 0-380 | ||
Milling head | Spindle speed | Standard:16 steps |
| 50HZ:60-4500/ 60HZ:80-5440 |
Optional:variable |
| 65-4200 | ||
Spindle taper |
| Standard: R8, Optional:ISO40 | ||
Motor power | HP | 3 | ||
Head rotating | Swiveling | deg | 90 | |
Tilting | deg | 45 | ||
CNC |
| GSK or FANUC | ||
Packing size(LxWxH) | mm | 1650x1900x2460 | ||
G.W. | kg | 1200 |
with FANUC 0i mate TD control system or with GSK983M control system
