CNC Milling Machine

Specifications

CNC Milling Machine
1. Rectangular guideways;
2. Famous controller;
3. Spindle aire flow;
4. Auto. lubricate;

CNC Milling Machine
1. Rectangular guideways;
2. Famous controller;
3. Spindle aire flow;
4. Auto. lubricate;



Model		KBM-1354B	KBM-1654	KBM-2063	KBM-2473
Table size(LxW/mm)		1370x330	1370x406	1600x510	1854x610
Table loading capacity(kg)		400	800	1200	1500
T-slots(W/mmxNO)		16x3	16x5	18x5	18x5
X-axis(mm)		800	1000	1200	1500
Y-axis(mm)		450	480	700	700
Z-axis(mm)		480	600	600	700
Max.move speed(mm/min)		8000	8000	10000	10000
Max.feed speed(mm/min)		3000	3000	4000	4000
Spindle speed(rpm/min)		RANGE:40~6000
Spindle nose		BT40	BT40	BT40/ BT50	BT40 /BT50
Spindle motor(kw)		5.5	7.5	7.5	7.5
Servo motor(kw)		X/Y:1.0,Z:1.5	X/Y/Z:1.5	X/Y/Z:2.0	X/Y/Z:2.0
Spindle quill diameter(mm)		120	150	150/160	150/160
Spindle to column surface(mm)		450	520	640	695
X-axis(mm)		32x5p4Double nuts	32x5p4Double nuts	40x10p4Double nuts
Y-axis(mm)		32x5p4Double nuts	40x5p4Double nuts	40x10p4Double nuts
Z-axis(mm)		32x5p4Double nuts	40x5p4Double nuts	40x10p4Double nuts
Positioning accuracy		±0.015mm	±0.015mm	±0.015mm	±0.015mm
Repeatability		±0.008mm	±0.008mm	±0.008mm	±0.008mm
Packing dimension(mm)	Semi-close cover	2250x2280x2450	2500x2280x2650	2900x2950x2800	2900x3150x2900
	Close cover	2950x2280x2450	3200x2280x2650	4500x2750x2800	/
Machine weight(kg)	Semi-close cover	2600	3800	5000	6000
	Semi-close cover	3400	4720	6400	/



Standard accessories:

*Semi-isolated table shield

*Cutting fluid circulation system

*Auto. Lubrication system

*Spindle air flow

*Working light

*Level adjusting screw and block

*Clamping apparatus



Optional accessories:

*The forth axis revolving table

*Vertical arm type ATC

* Full closed safety cover

*Cutter length measuring unit

*Edge finder

*Shank
