Help CenterCNC MILLING MACHINE
Related Products
-
CNC Horizontal Boring Milling MachineNegotiableMOQ: 1 Set -
Horizontal CNC Boring Milling Machine TXK-140NegotiableMOQ: 1 Set
-
CNC Horizontal Boring MachineNegotiableMOQ: 1 Set
-
ECONOMICAL CNC MILLING MACHINE KTM230, KTM250US$ 7,000 - 20,000MOQ: 1 Set
-
CNC Milling MachineUS$ 5,000 - 30,000MOQ: 1 Set
Specifications
1.CNC milling machine;2.Optional digital readout device;
3. With optional ATC equipment;
4.Semi-isolated table shield.
Features:
1. The spindle system features strong rigidity, it's suitable for rough machining and force cutting; hence improve machining efficiency, features long travel, heavy loading.
2. The machine can be used for drilling,boring,lathing and milling.
3. The machine is adoppt rectangular guide ways,featrues strong rigidity and high accuracy.
4. Radial tool holder of facing head on the headstock head for radial machining.
5. Optional digital readout device, reading accuracy 0.01mm,positioning accuracy 0.05mm.
| Specification | KBM-1354B | KBM-1654 | KBM-2063 | KBM-2473 |
| Table size(L×W/mm) | 1370×330 | 1370x406 | 1600x510 | 1854x610 |
| Table loading capacity(kg) | 400 | 800 | 1200 | 1500 |
| T-slots(W/mm×NO) | 16×3 | 16x5 | 18x5 | 18x5 |
| X-axis(mm) | 800 | 1000 | 1200 | 1500 |
| Y-axis(mm) | 450 | 480 | 700 | 700 |
| Z-axis(mm) | 480 | 600 | 600 | 700 |
| Max.move speed(mm/min) | 8000 | 8000 | 10000 | 10000 |
| Max.feed speed(mm/min) | 3000 | 3000 | 4000 | 4000 |
| Spindle speed(rpm/min) | range:40~6000 | |||
| Spindle nose | BT40 | BT40 | BT40/BT50 | BT40/BT50 |
| Spindle motor(kw) | 5.5 | 7.5 | 7.5 | 7.5 |
| Servo motor(kw) | X/Y:1.0,Z:1.5 | X/Y/Z:1.5 | X/Y/Z:2.0 | X/Y/Z:2.0 |
| Spindle quill diameter(mm) | 120 | 150 | 150/160 | 150/160 |
| Spindle to column surface(mm) | 450 | 520 | 640 | 695 |
| X-axis(mm) | 32×5p4Double nuts | 32×5p4Double nuts | 40×10p4Double nuts | |
| Y-axis(mm) | 32×5p4Double nuts | 40×5p4Double nuts | 40×10p4Double nuts | |
| Z-axis(mm) | 32×5p4Double nuts | 40×5p4Double nuts | 40×10p4Double nuts | |
| Positioning accuracy(mm) | ±0.015 | ±0.015 | ±0.015 | ±0.015 |
| Repeatability(mm) | ±0.008 | ±0.008 | ±0.008 | ±0.008 |
| Packing dimension(L×W×H)(mm) | 2250×2280×2450 | 2500x2280x2650 | 2900x2950x2800 | 2900x3150x2900 |
| Machine weight(kg) | 2600 | 3800 | 5000 | 6000 |
Standard Accessories:
Semi-isolated table shield, cutting fluid circulation system, auto.lubricaion system, spindle air flow, working light, level adjusting screw and block, clamping apparatus.
Optional Accessories:
The forth axis revolving table, vertical arm type ATC, full closed safety cover, cutter length measuring unit, edge finder, shank.
