Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > Strong Cutting CNC Milling Machine
Strong Cutting CNC Milling Machine
US$ 30,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
TIMAC
Model Number:
VMK740
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CNC MILLING MACHINEUS$ 5,000 - 30,000MOQ: 1 Set -
CNC Horizontal Boring Milling MachineNegotiableMOQ: 1 Set
-
Horizontal CNC Boring Milling Machine TXK-140NegotiableMOQ: 1 Set
-
CNC Horizontal Boring MachineNegotiableMOQ: 1 Set
-
ECONOMICAL CNC MILLING MACHINE KTM230, KTM250US$ 7,000 - 20,000MOQ: 1 Set
Condition
New
Brand Name
TIMAC
Model Number
VMK740
Type
Vertical
CNC or Not
CNC
Voltage
As require
Power(W)
7.5/11KW
Dimension(L*W*H)
2450x2400x2565mm
Weight
5000kg
Certification
TUV
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
| Specification | Unit | VMK740 | |
| Spindle taper | BT50 | ||
| X-axis travel | mm | 700 | |
| Y-axis travel | mm | 400 | |
| Z-axis travel | mm | 500 | |
| Maximum spindle speed | rpm | 4000 | |
| Distance spindle nose to table | mm | 150-650 | |
| Spindle center to column guideway surface distance | mm | 460 | |
| X / Y axis rapid feed | mm/min | 15000 | |
| Z-axis rapid feed | mm/min | 12000 | |
| Cutting feed | mm/min | 1-5000 | |
| Table area | mm | 1100×420 | |
| Maximum load capacity | kg | 500 | |
| Worktable "T" slots | Number of slots | 3 | |
| Width | mm | 18 | |
| Space | mm | 125 | |
| Main motor power | kW | 7.5/11 | |
| Machine weight | kg | 5000 | |
| Overall dimensions | mm | 2450×2400×2565 | |
Standard:
FANUC 0i mate MD CNC controller, BT50 spindle, Semi-closed protection guard
Optional:
Siemens 828D CNC controller, China make CNC controller, The-4th axis
