CNC Vertical Lathe

Name: CNC Vertical Lathe
Brand: TIMAC
SKU: 140795972
Availability: InStock

US$ 15,600 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Vertical

CNC or Not:

CNC

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Vertical

CNC or Not CNC

Brand Name TIMAC

Model Number VK-500, VK-600, VK-800

Specifications

CNC vertical lathe

CNC Vertical Lathe

1. Compact structure, rigid spindle component and good for heavy cutting;

2. Easy to chuck and remove, work piece roundness and other precision are ensured;

3. The turret on the slide moves along longitudinal or cross rails;

4. There are three cross rails to support the slide;

5. Ball screws and linear rails are used to ensure smooth feed and high precision;

6. Different handles, electric buttons and CRT displayer are all on the same rocking panel for easy operation;

7. Machine totally sealed guard structure.

Model	Unit	VK-500	VK-600	VK-800
Swing over bed	mm	530	800	1000
Max.turning diameter	mm	500	600	800
Max.turning height	mm	450	600	800
Speed range	r/min	100-2000	45-1000	50-2000
Spindle nose		A2-8	A2-11	A2-15
Spindle bearing diameter(front)	mm	120	160	200
Stroke of X-axis	mm	50-250	50-500	50-800
Stroke of Z-axis	mm	450	650	850
Rapid speed of X-axis	m/min	8	12	10
Rapid speed of Z-axis	m/min	10	12	10
Accuracy of positioning X/Z-axis	mm	0.018/0.02	0.018/0.02	0.018/0.02
repeat location accuracy X/Z-axis	mm	0.006/0.01	0.006/0.01	0.006/0.01
Type of tool post		Horizontal 8-position	Vertical 6-position	Vertical 6-position
Shank external cutting tool	mm	25X25	32×32	32×32
Boring tool	mm	Φ40	Φ32,Φ40,Φ50	Φ32,Φ40,Φ50
Main motor	kw	11	15	30/37
Motor of cooling pump	kw	0.9	1.1	1.1
Overall diamensions: L	mm	1590	3340	2642
Overall diamensions: W	mm	2670	2630	3478
Overall diamensions: H	mm	2545	3060	3638
Net weight	kg	5500	12000	15000
