Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > High Precision CNC Lathe

High Precision CNC Lathe

Name: High Precision CNC Lathe
Brand: TIMAC
SKU: 140795968
Availability: InStock

US$ 10,000 - 30,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not CNC

Brand Name TIMAC

Model Number CK-400N, CK-500N

Specifications

1. High precision CNC lathe
2. Swing dia.: 440, 500mm
3. FANUC 0i mate TD system
4. GSK980TD system
5. Intverter spindle

High precision CNC lathe

Features:
1. Longitudinal and cross feeds are effected by ball leadscrews. Driven by servo motors.
2. Either vertical or horizontal 4-station or 6-station tool post or gang tools can be selected. The post is located on precision contrite gears with a high repeated positioning accuracy.
3. Both chuck and tailstock are supplied with hydraulic or manual type.

4. The spindle system is high in the rigidity and accuracy.

Specification	CK-400N	CK-500N
Max. swing over bed	Ø440mm	Ø500mm
Max. swing over carriage	Ø210mm	Ø295mm
Width of bed	405mm
Maximum turned length	1000mm/1500MM
Max. turning length	900mm
Spindle nose	A2—6	D8
Spindle bore	Ø56mm	Ø80mm
Cone hole diameter and taper of spindle hole	MT.No6	MT.No7
Steps of spindle speed(Manual)	Variable	3(variable within each step)
Range of spindle speed	450~2800 r/min	40~165,160~660,660~2000r/min
Rapid feed for Axis Z	10m/min
Rapid feed for Axis X	8 m/min
Max. travel of Axis Z	920mm
Max. travel of Axis X	290mm	310mm
Min. input	0.001 mm
Tool post stations	4-ways
Tool cross section	25×25 mm	32×32 mm
External diameter	Ø75mm
Taper of bore	MT.No.5
Max. Traverse	150mm
X/Z motor torque	4.7/7Nm	7/9.5Nm
Power of main motor	5.5 KW	7.5 KW
Power of cooling pump	90W
Overall dimensions(L×W×H)	2630×1400×1550mm	2530×1400×1600mm
Net weight	2700kg	2850kg

Standard:

FANUC 0i mate TD CNC system, FANUC servo feed motor, Inverter main motor, 3 jaw chuck, 4 station electric tool post, Coolant supply system, Auto. Lubrication unit, Lighting unit, General tools, Operation and maintenance manuals (English edition), etc.

Optional:

GSK980TD controller, 6 station electric toolpost, Hydraulic chuck, Hydraulic tailstock
