Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > Full Function CNC Lathe/Slant Bed Type CNC Lathe

Full Function CNC Lathe/Slant Bed Type CNC Lathe

Name: Full Function CNC Lathe/Slant Bed Type CNC Lathe
Brand: TIMAC
SKU: 140795926
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

Full Function CNC Lathe/Slant Bed Type CNC Lathe thumbnail-1

Full Function CNC Lathe/Slant Bed Type CNC Lathe photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China port.

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 520mm/850mm

Place of Origin Henan, China

Brand Name TIMAC

Model Number AK-10, AK-15B, AK-25, AK-35,AK-45

Voltage As request

Certification ISO,CE Standard

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Universal CNC lathe;
2. Turning accuracy IT5-IT6 ;
3. Semi-closed loop CNC machine.

Specification	Unit	AK-10	AK-15B	AK-25	AK-35	AK-45
Swing over bed	mm	360	440	520	660	850
Max. turning dia. over bed	mm	300	320	420	550	800
Max. turning dia. over carriage	mm	170	220	360	420	650
Max. turning length	mm	500/750/1000	450/700/950	530/905/1405/ 1905/2905/3905	780/1530/1890 /2890/3890	900/1400/1900 /2900/3900
Distance between centers	mm	600/800/1100	600/850/1100	625/1000/1500/ 2000/3000/4000	890/1640/2000 /3000/4000	1000/1500/2000 /3000/4000
Max. bar capacity	mm	36	52	70	80	120/150
X-axis travel	mm	170	190	230	305	450
Z-axis travle	mm	510/7601010	510/760/1010	590/965/1465 /1965/2965/3965	855/1605/1965 /2965/3965	950/1450/1950 /2950/3950
Rapid traverse (x- and z- axis)	m/min	18/20	18/20	12/15	12/15	12/15
Cutting feed (x- and z- axis )	mm/min	5000	5000	5000	5000	5000
Hand feed (x- and z- axis )	mm/min	1260	1260	1260	1360	1260
Spindle speed	rpm	50-5000	50-4500	35-3500	25-2500	0-2000
Spindle nose		A2-5	A2-6	A2-8	A2-8	A2-11/A2-15
Size of chuck	inch	6"	8"	10"	12"	15"
Spindle front end bearing (dia)	mm	80	100	130	160	200
Spindle bole (dia)	mm	50	62	87	92	131
Number of stations		8	8	12	12	12
Indexing time	s	0.58	0.58	1	1	0.9
Tool shank size	mm	25×25	25×25	25x25	25x25	32x32
Boring bar shank dia.	mm	32	40	40	50	60
Main spindle motor	kw	7.5/11	9/11	18.5/15	30/22	100
X-axis servo motor	kw	1.2	1.6	1.6	3	4
Z-axis servo motor	kw	1.8	1.6	3	4	7
Max. travel	mm	360/610/860	360/610/860	490/865/1365/ 1865/2865/3865	760/1500/1900 /2900/3900	900/1400/1900 /2900/3900
Quill dia.	mm	80	80	85	110	140
Quill travel	mm	100	100	80	100	130
Quill taper hole		MT-4	MT-4	MT-5	MT-5	MT-6
Coolant capacity	L	120	120	200/230/280/330	200/250/280/350	450
Power	kw	20	25	30	46	130
X-axis positioning accruacy	mm	0.025	0.025	0.025	0.025	0.025
X-axis repositioning accuracy	mm	0.01	0.01	0.01	0.01	0.01
X-axis reverse warp	mm	0.012	0.012	0.012	0.012	0.012
Z-axis positioning accruacy	mm	0.016	0.016	0.016	0.016	0.016
Z-axis repositioning accuracy	mm	0.007	0.007	0.007	0.007	0.007
Z-axis reverse warp	mm	0.006	0.006	0.006	0.006	0.006
