Full Function CNC Lathe/CNC Turning Center KL-25,KL-25H

Name: Full Function CNC Lathe/CNC Turning Center KL-25,KL-25H
Brand: TIMAC
SKU: 140795884
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

Full Function CNC Lathe/CNC Turning Center KL-25,KL-25H thumbnail-1

Full Function CNC Lathe/CNC Turning Center KL-25,KL-25H photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China port.

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 500mm

Place of Origin Henan, China

Brand Name TIMAC

Model Number KL-25,KL-25H

Voltage As request

Power(W) 11/15kw

Dimension(L*W*H) 3712x1660x1850mm

Weight 4500kg

Certification CE,ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.High precision slant bed cnc lathe
2.Swing over bed 500mm
3.Max. workpiece length 500mm
4. Power tool turret

Features:
1. It is suitable for auto parts, valves and other similar parts large number machining as well as mediumand small number production.
2. Using FANUC control system and servo motors.
3. Using Lio Shing tool post enables it to select the nearest tool. Time for tool change is only 0.3 second.
4. The spindle is supported by SKF series bearings.
5. An automatic timely lubrication device is supplied for the machine.
6. It has a stainless steel inner protection and a totally sealed outside protection.

Specification	KL-25	KL-25H
Max. swing over bed	Φ500mm
Max. cutting dia. For disc parts	Φ420mm	370mm
Max. cutting dia. For axle parts	Φ250mm
Max. cross travel (X)	220mm
Max. longitudinal travel (Z)	550mm	500mm
Max. legth of workpiece	500mm	420mm
Rapid feed for axis X	12m/min
Rapid feed for axis Z	20m/min
Max. speed of spindle	4000rpm
Diameter of spindle thru hole	Φ65mm
Spindle nose	A2-6
Taper bore of spindle	MetricΦ80mm 1:20
Min. index of C axis	0.001°
Hydraulic chuck	8”
Number of tools	12 Hydraulic	12 powered
Sevo motor power for powered tool	-	2.2/3.7Kw
Max. speed of power tool	-	5000r/min
Outside dia. Of cutting tool shand	25x25mm	20x20mm
Inner dia. Of cutting tool shank	Φ40mm	Φ32mm
Tailstock sleeve dia.	Φ80mm
Tailstock sleeve travel	100mm
Taper hole of tailstock quill	M.T.No.4
Min. Input	0.001mm
Bed structure	45° slant bed integrated with stand
Main motor power	11/15KW
Tool compensation model	Wear/geometric
Overall dimensions(L×W×H)	3712×1660×1850
Net weight	4500Kg

Standard Accessories:

FANUC 0i Mate TD controller, FANUC servo type feeding motor for both X,Z axes, NSK bearings, Hydraulic chuck, Hydraulic tool turret, Hydraulic tailstock, Automatical lubricating unit, Cooling system, Tools, Operational manual(English edition), etc.
