Specifications
1. CNC vertical lathe machine2. Standard Siemens 802DSL system
3. Turning dia. 1250mm
CNC SINGLE COLUMN VERTICAL LATHE MACHINE
Features:
1. It adopts the identical modules(identical beam section, beam slide base, rotary slide base, ram, aervo motor) which are extremely suitable for heavy-load cutting.
2. The working platform owns the function of waterproof and it is not necessary to worry that cutting fluid infiltrates into it. The design of square shaped working platform facilitates the collection of cutting fluid.
3. Siemens 802DSL system(user can appoint other system), servo motor and servo drive all utilize Siemens products.
4. Beam guiding surface and T model ram guideway is conducted with supersonic frequency quenching treatment with the characteristics of durable service; the sliding surface is sticking with the soft plastics belt, which can prolong the overhaul period for over 10 years at least.
5. The independent electric cabinet is equipped with air conditioner for refrigerating, which prolongs the reliability and service life of the electric parts significantly, facilitates repair and maintenance, and is free from the influence of machine vibration.
6. P3 high-precision lead screw produced by Nanjing Process or Taiwan HIWIN (P1 is the highest and P6 is the lowest degree), and imported bearing support.
7. The beam is protected by the white steel, and all the lubrication parts are supplied with certain amount of oil by the automatic lubricating pumps regularly.
8. Four-grade machine variable speed + motor stepless variable speed, wide range of constant power and large torque. Four station electric tool post, automatic exchange tool, convenient and practical.
9. JB/T9934.1-1999 precision inspection of CNC vertical lathe is performed; JB/T9934.2-1999 technical specification of CNC vertical lathe
10. Owning constant line speed turning, cutting thread and other functions
11. High-precision transmission gear (6 grades) and high-precision spiral bevel gear (6 grades) with low noise and high rotary precision.
12. All the castings are made of HT300 grey cast iron which is treated with artificial heat ageing, high-quality processing and improved assembly process. All the functional parts and electric parts are in high quality with high reliability.
13. Complete fitting configuration allows the user to put into operation only by preparing cutting tool and measuring tool. The improved after-sales service and 1-year quality assurance service are available.
14. Optional parts: Germany Mecano button station, constant flow hydrostatic guideway, oil temperature icebox, constant temperature refrigerator, grating closed loop, heighten lathe body, lengthen ram etc.
Specifications | Unit | VK-125 |
Max. turning diameter | mm | 1250 |
Table diameter | mm | 1000 |
Max. turning height | mm | 1000/1200 |
Rotate range of table | r/min | 0.5-250 |
Stage number of variable speed |
| Four gears + stepless |
Max. cutting force of vertical tool post | N | 25000 |
Max. torque of table | N.m | 20000 |
Level stroke of vertical tool post | mm | 850 |
Vertical stroke of vertical tool post | mm | 700 |
Tool rest form |
| 4 station |
Beam stroke | mm | 650 |
Tool rest rapid traverse speed | mm | 1000/6000 heavy-duty cutting model |
Beam lifting speed |
| 440 |
Sectional dimension of cutter bar(LxW) | m/min | 40x40/32x32 |
Main motor power | mm | 30/37 |
Accuracy of positioning | Kw | 0.03 |
Accuracy of repositioning | mm | 0.015 |
Machining accuracy |
| IT7 |
Overall size(LxWxH) | mm | 2360X2277X3403 |
Weight | T | 8 |
