Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > CK-360S Flat Bed Type CNC Lathe With 360mm Swing

CK-360S Flat Bed Type CNC Lathe With 360mm Swing

Name: CK-360S Flat Bed Type CNC Lathe With 360mm Swing
Brand: TIMAC
SKU: 140795864
Availability: InStock

CK-360S Flat Bed Type CNC Lathe With 360mm Swing thumbnail-1

CK-360S Flat Bed Type CNC Lathe With 360mm Swing photo-1

US$ 5,000 - 20,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 360mm

Place of Origin Henan, China

Brand Name TIMAC

Model Number CK-360S

Voltage As Customer's Request

Power(W) 3.7KW

Certification ISO, CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Flat bed type cnc lathe;
2. Swing dia. 360mm;
3. Spindle bore 40mm;
4. FANUC or GSK CNC controller;

FLAT BED TYPE CNC LATHE

Features:

1. The machine adopts global famous controller with RS232 interface.

2. Longitudinal and cross feeds are effected by ball leadscrews .

3. Either vertical or horizontal 4 station or 6 station tool post or gang tools can be selected.

4. The post is located on precision contrite gears with a high repeated positioning accuracy.

5. Both chuck and tailstock are supplied with hydraulic or manual type.

6. The surface of the guideways is supersonic frequency hardened and precision ground with long service life.

7. The spindle system is high in the rigidity and accuracy.

8. An inverter is used to realize variable speed.

Specification	Unit	CK-300S	CK-360S	CK-400S
Max. swing dia. over bed	mm	300	360	400
Max. swing dia. over carriage	mm	135/100	180/100	225/150
Center distance	mm	500	500/750/1000
Max. turning length	mm	460	450/700/950
Spindle nose		D4	C5	C6
Spindle bore	mm	38	40	52
Spindel taper		MT.No.5	MT.No.5	MT.No.6
Steps of spindle speed		Variable	Variable	Variable
Range of spindle speed	rpm	200~3500	200~2800
Rapid feed for axis Z	m/min	10
Rapid feed for axis X	m/min	8
Max. travel of axis Z	mm	460	490/740/990
Max. travel of axis X	mm	180/270	215/300
Min. input	mm	0.001
Tool post stations		4/ 6/gang type
Tool section	mm	16x16	20x20
Tailstock sleeve diameter	mm	50	60
Tailstock sleeve taper		MT.No.3	MT.No.4
Tailstock sleeve travel	mm	130	120
X/Z motor torque	Nm	3.6/4.7	3.6/4.7
Main motor power	kw	3	3.7	3.7(5.5)
Cooling pump power	w	75
Overall dimension(L×W×H)	mm	1500x945x1380	1870/2120/2370x1200x1415
Net weight	kg	1100	1500/1700/1900	1600/1800/2000

Standard Accessories: GSK980TDb CNC controller, FANUC servo feed motor, Inverter main motor, 3 jaw chuck, 4 station electric tool post, Coolant supply system, Auto. Lubrication unit, Lighting unit, General tools, Operation and maintenance manuals (English edition), etc.

Optional Accessories: Other brand CNC controller(FANUC 0i mate TD controller), 6 stations electric tool post, Gang type tool post, Hydraulic solid chuck, Hydraulic hollow chuck, Hydraulic tailstock.
