UTR-18x3000 Upper Roll Universal Three Rollers Rolling Machine

Name: UTR-18x3000 Upper Roll Universal Three Rollers Rolling Machine
Brand: TIMAC
SKU: 140795664
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

US$ 5,000 - 30,000 MOQ: 1 Set

Key Specifications

Brand Name:

TIMAC

Model Number:

UTR-18x3000

Machine Type:

Roll Forming Machine

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Brand Name TIMAC

Model Number UTR-18x3000

Machine Type Roll Forming Machine

Raw Material Sheet / Plate Rolling

Material / Metal Processed Other, Steel

Power Hydraulic

Automation Automatic

Extra Services Buffing / Polishing

Specifications

Uppe roller universal three roller rolling machine UTR-18x3000
Metal sheet/plate bending machine
With pre-bending function

Upper Roll Universal Three Rollers Rolling Machine Model UTR-18x3000

Description	Parameter
Press (ton)	130
Max.Rolling thickness (mm)	18
Max.pre-rolling thickness (mm)	14
Plate width (mm)	3000
Upper roller diamater (mm)	350
Roller work length (mm)	3300
Bearing	ZWZ
Lower roller diameter (mm)	165
Distance between two rollers center (mm)	350
Coiling speed (m/min)	4.5
Roller number	4
Roller number of group	1
Main motor power (kw)	15
Hydraulic motor power (kw)	5.5
Move motor power (kw)	0.75
Reducer model	ZSY Hardened reducer
Dimension size(LxWxH) (mm)	5050x1200x1680
Weight (ton)	6.5
