EHP CNC Electric Hydraulic Synchro Press Brakes(400T-2400T)

EHP CNC Electric Hydraulic Synchro Press Brakes(400T-2400T) thumbnail-1
EHP CNC Electric Hydraulic Synchro Press Brakes(400T-2400T) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
TIMAC
Model Number:
400/3200, 400/8000, 500/7000, 700/6000, 800/8000,..., 2400/6000
Machine Type:
Press Brake
Contact Supplier Request Quote Chat Now
Zhengzhou Timeway Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
CHINA PORT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name TIMAC
Model Number 400/3200, 400/8000, 500/7000, 700/6000, 800/8000,..., 2400/6000
Machine Type Press Brake
Raw Material Sheet / Plate Rolling
Power Other, Electric, Hydraulic, CNC
Automation Automatic

Specifications

EHP CNC Electric Hydraulic Synchro Press Brakes(400T-2400T)

EHP CNC Electric Hydraulic Synchro Press Brakes(400T-2400T)



* Combined structure.

* Stand configuration with 3+1 axes:

Y1 (upward-downward of left cylinder),

Y2 (upward-downward of right cylinder),

X (forward-backward of backguage),

V (hydraulic crowning ),

Optional 4+1 axes,6+1 axes,8+1 axes or more axesb according to user's needs.

* CYBELEC DNC600S  is the standard system, DNC60S,DNC880S,ModEva 10S,ModEva 12S are optional.

* Using the mechanical crowning mechanism,horizontal compensation can be controlled by the DNC system automatically,or manually fine tune the adjustments.

* All major electrical  and hydraulic elements are assembled with high grade international brands.

* A set of standard tools is provided with each machine,special tools are available according to customer's requirements.



Model Max. bending pressure (KN) Max. bending width (mm) Distance between uprights (mm) Opening height (mm) Throat depth (mm) Cylinder stroke (mm) Main power (KW) Dimensions (mm) Weight (kg)
Length (mm) Width (mm) Height (mm)
40032 4000 3200 2700 500 400 250 30 3465 3215 4250 25600
40040 4000 4000 3300 4265 3215 4370 27800
40050 4000 5000 4000 5265 3215 4710 33500
40060 4000 6000 5000 6265 3215 5020 37500
40070 4000 7000 5600 7265 3215 5355 42800
40080 4000 8000 6600 8250 3260 5960 49800
50032 5000 3200 2700 600 450 300 37 3465 3450 4665 33200
50040 5000 4000 3300 4265 3450 4660 40000
50050 5000 5000 4000 5265 3450 4750 46200
50060 5000 6000 5000 6265 3450 5070 53000
50070 5000 7000 5600 7265 3450 5400 58000
60040 6000 4000 3300 650 500 350 45 4265 3285 5160 48000
60050 6000 5000 4000 5265 3285 5335 54800
60060 6000 6000 5000 6265 3285 5560 62000
60070 6000 7000 5600 7265 3285 6080 69000
70040 7000 4000 3300 700 600 350 45 4250 3000 5400 56000
70050 7000 5000 4100 5250 3000 5650 62000
70060 7000 6000 5000 6250 3000 5900 69000
70070 7000 7000 5800 7250 3000 6300 76000
80040 8000 4000 3300 800 600 400 2X37 4250 3400 5960 65000
80050 8000 5000 4100 5250 3400 6200 74000
80060 8000 6000 5000 6250 3400 6500 86000
80070 8000 7000 5800 7250 3400 6750 98000
80080 8000 8000 6600 8250 3400 7000 110000
100050 10000 5000 4000 1000 800 400 2X45 5250 3800 6980 94000
100060 10000 6000 5000 6250 3800 7200 100000
100070 10000 7000 5800 7250 3800 7600 115000
100080 10000 8000 6600 8250 3800 8000 130000
125050 12500 5000 4000 1000 800 600 2X45 5250 4300 7300 115000
125060 12500 6000 5000 6250 4300 7650 130000
125070 12500 7000 5500 7250 4300 7950 145000
125080 12500 8000 6800 8250 4300 8300 160000
150060 15000 6000 5000 1200 800 600 2X55 6250 4600 8500 165000
150070 15000 7000 5800 7250 4600 8700 180000
150080 15000 8000 6800 8250 4600 8950 200000
165060 15000 6000 5000 1200 800 600 2X55 6250 4800 8500 170000
165070 15000 7000 5800 7250 4800 8700 185000
165080 15000 8000 6800 8250 4800 8950 210000
200050 20000 5000 4000 1200 1100 600 2X75 5280 5940 7870 184000
240060 24000 6000 5000 1300 1200 600 2X75 6280 7080 8980 252000
