Changan Small Roll off Steel Bins Truck

Name: Changan Small Roll off Steel Bins Truck
Brand: CCAG
SKU: 140782486
Availability: InStock

US$ 9,000 - 11,000 MOQ: 1 Set

Key Specifications

Condition:

New

Drive Wheel:

4x2

Type:

Recycling

Hubei Ocean Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Drive Wheel 4x2

Type Recycling

Transmission Type Manual

Emission Standard Euro 4

Volume 1000 - 3000L

Fuel Type Petrol / Gasoline

Engine Capacity 1012ml

Size 3920X1480X1920mm

Gross Vehicle Weight 1810

Place of Origin Hubei, China

Brand Name CCAG

Model Number CLQ5020ZXXSC4

Certification ISO9001-2008 3C

After-sales Service Provided Engineers available to service machinery overseas

Changan small roll off steel bins truck

Specifications:

Main specifications
Product model,name			CLQ5020ZXXSC4 Garbage Truck With Removable Box
Gross weight(Kg)			1810		Driving type			4×2
Payload (Kg)			680		Overall dimension (mm)			3920×1480×1920
Curb weight(Kg)			1000		cab seats (man)			2
Approach/departure angle (°)			58/20		Front/rear hang(mm)			480/940
Axle No.			2		Wheelbase (mm)			2500
Axle load(Kg)			925/885		Max speed(Km/h)			98
Chassis specifications
Chassis model	SC1022DB4N4			Manufacture		Hebei changan automobile co., LTD
Brand name	CCAG			Overall dimension (mm)		3800×1480×1810
Tire specification	165/70R13LT			Tires No.		4
Steel spring number	-/5			Front track(mm)		1280
Fuel type	gasoline			Rear track(mm)		1290
Emission standard	Euro 4			Gear box		5 forward and 1 rear
Engine model	Engine manufacture					displacement(ml)			Power(Kw)
JL466Q1	Chongqing changan automobile co., LTD					1012			50.7
Performance
Body capacity(m³)		2.5		Body material			Q235 carbon steel
Discharge Method		Rear dump		Operation control system			Manuel + electric
Characteristic
1,Detachable Container Garbage Truck also called pull arm garbage truck ; 2,Using full hydraulic control , the operator can do the waste bin lifting, discharging and dumping both in the driving room or out of the room, and all the operations can be performed by one driver in the cab; 3,The truck compartment using fully enclosed design,there is no water leakage while transportation, that is avoid the secondary pollution problem, make it more environmental friendly; 4,The truck can equipped with several garbage box, one truck can maintain multiple garbage collection point operation, high efficiency.
