Home > Products > Garbage truck > DongFeng 4x2 small hook lift truck
DongFeng 4x2 small hook lift truck
- 100 Set / Sets per Month
- any port according to your requirement
- T/T
- Small Dust cart, garbage truck 3TON,4TON,5TON
- Constructed mining small garbage transfer truck/site dumper on sale
- 4wd 1.5ton Dumper Truck, 4wd Small Garbage Truck Compactor with Factory Price Automatic Provided 0.7CBM 1500kg 3320-2780*2150
- New Design Electric Power 48V Three Wheel Cleaning Tricycle For Garbage Green Energy BJ3014
- Mobile garbage compactor container 8cbm 10cbm 12cbm 16cbm 18cbm 20cbm
- 3cbm 4cbm 5cbm 6cbm 8cbm 10cbm 12cbm hook lift bin for hook arm garbage truck
Product Details
Condition: | New | Drive Wheel: | 4x2 | Type: | Other, detachable container garbage truck |
Transmission Type: | Manual | Emission Standard: | Euro 4 | Volume: | 6001 - 10000L |
Fuel Type: | Diesel | Engine Capacity: | 3856ml | Size: | 6815*2080*2440mm |
Gross Vehicle Weight: | 8275 | Place of Origin: | Hubei, China | Brand Name: | dongfeng |
Model Number: | CLW5080ZXXD4 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
DongFeng 4x2 small hook lift truck
Factory direct sale,best price
Certificate ISO9001,3C
diesel engine
dustbin can lift by the hydraulic system ,the garbage box is a hermetic box large capactiy easy control and operate
Specifications of the truck
Main specifications | |||||||||
Product model,name | CLW5080ZXXD4 Garbage Truck With Removable Box | ||||||||
Gross weight(Kg) | 8275 | Driving type | 4×2 | ||||||
Payload (Kg) | 4380 | Overall dimension (mm) | 5830×2100×2440 | ||||||
Curb weight(Kg) | 3700 | cab seats (man) | 3 | ||||||
Approach/departure angle (°) | 24/28 | Front/rear hang(mm) | 1210/820 | ||||||
Axle No. | 2 | Wheelbase (mm) | 3800 | ||||||
Axle load(Kg) | 3310/4965 | Max speed(Km/h) | 99 | ||||||
Chassis specifications | |||||||||
Chassis model | DFA1080SJ12D3 | Manufacture | Dongfeng Automobile Company | ||||||
Brand name | Dongfeng | Overall dimension (mm) | 6815×2080×2440 | ||||||
Tire specification | 7.50R16 | Tires No. | 6+1 | ||||||
Steel spring number | 8/10+7,11/9+7 | Front track(mm) | 1770 | ||||||
Fuel type | Diesel | Rear track(mm) | 1586 | ||||||
Emission standard | Euro 4 | Gear box | 5 forward | ||||||
Engine model | Engine manufacture | displacement(ml) | Power(Kw) | ||||||
CY4102-CE4C | Dongfeng chaoyang chaochai power company | 3856 | 91 | ||||||
Performance | |||||||||
Body capacity(m³) | 6 | Body material | Q235 carbon steel | ||||||
Discharge Method | Rear dump | Operation control system | Manuel + electric | ||||||
Characteristic | |||||||||
1,Detachable Container Garbage Truck also called pull arm garbage truck ; 2Using full hydraulic control , the operator can do the waste bin lifting, discharging and dumping both in the driving room or out of the room, and all the operations can be performed by one driver in the cab; 3The truck compartment using fully enclosed design,there is no water leakage while transportation, that is avoid the secondary pollution problem, make it more environmental friendly; 4The truck can equipped with several garbage box, one truck can maintain multiple garbage collection point operation, high efficiency. |
Pictures of the truck
