120A Portable Welding Generator

Name: 120A Portable Welding Generator
Brand: YARMAX
SKU: 140761378
Availability: InStock

US$ 320 - 415 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

YARMAX

Model Number:

KDE120-W

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name YARMAX

Model Number KDE120-W

Output Type AC Single Phase

Speed 3000/3600rpm/min

Frequency 50/60

Rated Power 1.7KW

Rated Voltage 220V

Rated Current 7.7

Specifications

Welding Generator
Portable Welder generator
Werlder and generator
120A Welder generator

MODEL	KDE120EW	KGE120EW
Rated Current (A)	100
Rated Voltage (V)	21-25
Welding Current Range (A)	40-120
Applicable Electrode (Æ)	1.2-2.5
Duty cycle	120A/20%,100A/60%
Generator voltage waveform distortion rate	5%
Phase	Single Phase
Frequency (Hz)	50/60
Rated Output (kw)	1.5/1.7
Rated Voltage (V)	110,120,220,230,240
Power Factor	1.0
Model	KM178F	KM210F
Max. Output(HP)	6.0	7.0
Displacement(cc)	306	208
Type	Single-cylinder,4-stroke,air-cooled,Vertical	Single-cylinder,4-stroke,OHV,Air-cooled,
Compression ratio	20:01	8.3:1
Starting System	Recoil or Electric Start
Lubrication System	Forced lubrication
Cooling System	Air cooled
Fuel Tank (L)	3.5L diesel	3.6L gasoline
Oil Capacity (L)	1.1	0.6
Noise Level(at 7m)	76	66
Dimension(LXWXH)mm	735x460x530	695x425x420
G.W (kg)	75	45
