China Supplier Motor Generator Welding Machine

Model

KDE300EW

Frequency(HZ)

50

60

Rate power(KVA)

3

3.2

Voltage(V)

230

240

Current(A)

13.0

13.3

Engine speed(r/min)

3000

3600

NO-load welding voltage(V)

60

Rated welding voltage(V)

21-34

Rated welding DC A

270

Current adjusting extension A

50-300

Welding Electrode φ (mm)

1.6-6.0

Welding load continuous ratio

50%

Phase

Single

Power factor

COS=1

Excitation system

(with AVR) Self-excited constant voltage

Noise level (7m) dB(A)

79

Fuel tank capacity(L)

25

Structure

Open-frame

Panel

Ordinary

DC12VOutput

12V./8.3A,Connection Pole Output

Dimension(L*W*H)(mm)

930x690x920

Net weight(kg)

200

Engine model

KM840

Engine type

2-V-twin, four-stroke, air-cooled,

direct injection

Bore*stroke(mm)

2-86x72

Displacement(L)

0.836

Power(KW)

10.3/3000

11.3/3600

Fuel consumption rate (g/k w. h)

≤270

≤290

Compression ratio

19

Lubrication system

Forced & splashing

Diesel oil model

0#(summer),-10#(winter), diesel

Lube oil model

SAE10W-30 (above CD grade)

Lube oil capacity(L)

1.7

Starting system

Electric starter

Battery capacity(V-AH)

12V-36Ah
