3kw Open Type Diesel Generator

Name: 3kw Open Type Diesel Generator
Brand: Sumokama
SKU: 140761046
Availability: InStock

US$ 300 - 800 MOQ: 30 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Sumokama

Model Number:

KDE6500

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number KDE6500

Output Type AC Three Phase

Speed 3000/3600RPM

Frequency 50/60HZ

Rated Power 3KW

Rated Voltage 120/240

Specifications

Alternator with brush and automatic voltage regulator (AVR) provide stable output voltage and current .

Model	Economical type						Luxury type
	KDE2500CL(E)		KDE4000CL(E)		KDE5500CL(E)		KDE2500CX(E)		KDE4000CX(E)		KDE5500CX(E)
Alternator-Type	Revolving field type 2pole generator
Frequency (Hz)	50	60	50	60	50	60	50	60	50	60	50	60
Rated output(kW)	1.7	2	2.8	3.3	4.2	5	1.7	2	2.8	3.3	4.2	5
Voltage(A.C)(V)	230	120/240	230	120/240	230	120/240	230	120/240	230	120/240	230	120/240
DC output(A.C)(V-A)	7.4	8.3/16.7	12.2	13.8/27.5	18.3	20.8/41.7	7.4	8.3/16.7	12.2	13.8/27.5	18.3	20.8/41.7
Engine speed(r/min)	3000	3600	3000	3600	300	3600	3000	3600	3000	3600	3000	3600
Power factor(% )	1
Excitation System	Controlled Constant Operation
D.C output V/A	12V/8.3A
Coupling Pattern	Straight Shaft Coupling
Engine Model	170FG(E)		178FG(E)		186FG(E)		170FG(E)		178FG(E)		186FG(E)
TYPE	Direct injection Vertical, 4cycle, air cooled diesel engine
Displacement cc(cu.in)	211(12.88)		296(18.06)		406(24.78)		211(12.88)		296(18.06)		406(24.78)
Rated Output(kw/rpm)	2.5	2.8	4	4.4	5.9	6.6	2.5	2.8	4	4.4	5.9	6.6
Max.Output(kw/rpm)	2.8	3.1	4.4	4.6	6.6	7.35	2.8	3.1	4.4	4.6	6.6	7.35
Starting system	Recoil start						Recoil start(Electric start)
Governor system	Centrifugal weight system
Fuel tank capacity(L)	2.5		3.5		5.5		7.5		13.5		15
Lube oil capacity(L)	0.8		1.1		1.65		0.8		1.1		1.65
BorexStroke(mm)	70x55		78x62		86x70		70x55		78x62		86x70
Protection system	CX: Low oil, warning system/stop device
Dim LxWxH(mm)	630x500x525		700x500x565		720x500x625		630x500x525		700x500x565		720x500x625
N.W.(kg)	46		61		95		65		80		95
Noise level at 7m dBA	79		82		85		79		82		85
