Diesel Generator 2KW/3KW/5KW/6KW

Name: Diesel Generator 2KW/3KW/5KW/6KW
Brand: Sumokama
SKU: 140761052
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Sumokama

Model Number:

KDE2500/3500/6700T-A

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number KDE2500/3500/6700T-A

Output Type Other, single/3 Phase

Specifications

CE approval & ISO9001:2008
Portable generator
1 year warranty & spare parts
100% Copper Wire Alternator
Electric Start

Our Advantages:

1. Solve your technical problems in 24 hours and provide international warranty service for engines

2. Design the appearance form according to customers’ request

3. Polyester varnish for appearance protecting for shining and raining

4. Four hours testing before out factory and CCIB inspection

5. ISO9001 and CE certification

Model	KDE2500E
Frequency (HZ)	50	60
Rated Output (KVA)	1.7	2.0
Maximum Output (KVA)	2.0	2.2
Rated Voltage (V)	115/230	120/240
Rated current (A)	14.8/7.4	16.7/8.3
Rated rotation speed (rpm)	3000	3600
Phase No.	Single phase
Power Factor	1.0
Excitation Mode	Self-excitation, 2 pole and constant voltage (AVR)
DC Output	12V. /8.3A , Terminal Post
Noise Level (7m) dB(A)	77
Engine Model	KM170FE
Engine type	Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel
Bore × Stroke(mm)	70 x 55
Displacement (L)	0.211
Rated Power KW	2.5/3000	2.8/3600
Fuel comsumption Rate(g. kw/h)	280.2	288.3
Compression Ratio	20: 1
Lubrication System	Pressure Splashed
Starting System	Electric Start with 30Ah MF battery
Fuel Type	0#(summer)-10#(winter) diesel
Lube Oil Brand	SAE10W30 (above CD Grade)
Lube Capacity (L)	0.75
Fuel Tank Capacity (L)	12.5
Continuous Running Time (hr)	20
Overall Dimension: LxWxH (mm)	660 x 500 x 570
Dry Weight (Kg)	60
Quantity in 20FT	132 Pcs
Optiomal Features: Remote, ATS(Auto Transfer Switch), Digital Panel
We reserve the right to change specifications without notice

Model	KDE3500E
Frequency (HZ)	50	60
Rated Output (KVA)	2.8	3.0
Maximum Output (KVA)	3.0	3.2
Rated Voltage (V)	115/230	120/240
Rated current (A)	24.4/12.2	25/12.5
Rated rotation speed (rpm)	3000	3600
Phase No.	Single phase
Power Factor	1.0
Excitation Mode	Self-excitation, 2 pole and constant voltage (AVR)
DC Output	12V. /8.3A , Terminal Post
Noise Level (7m) dB(A)	72
Engine Model	KM178FE
Engine type	Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel
Bore × Stroke(mm)	78 x 62
Displacement (L)	0.296
Rated Power KW	3.68/3000	4.0/3600
Fuel comsumption Rate(g. kw/h)	276.1	285.6
Compression Ratio	20: 1
Lubrication System	Pressure Splashed
Starting System	Electric Start with 30Ah MF battery
Fuel Type	0#(summer)-10#(winter) diesel
Lube Oil Brand	SAE10W30 (above CD Grade)
Lube Capacity (L)	1.1
Fuel Tank Capacity (L)	12.5
Continuous Running Time (hr)	12
Overall Dimension: LxWxH (mm)	710 x 500 x 590
Dry Weight (Kg)	70
Quantity in 20FT	132 Pcs
Optiomal Features: Remote, ATS(Auto Transfer Switch), Digital Panel
We reserve the right to change specifications without notice

Model	KDE6700TA
Frequency (HZ)	50	60
Rated Output (KVA)	4.5	5
Maximum Output (KVA)	5	5.5
Rated Voltage (V)	115/230	120/240
Rated current (A)	39.1/19.6	41.7/20.8
Rated rotation speed (rpm)	3000	3600
Phase No.	Single phase
Power Factor	COS=1
Excitation Mode	Self-excitation, 2 pole and constant voltage (AVR)
DC Output	12V. /8.3A , Connection Pole Output
Structure Type	Soundproof
Noise Level (7m) dB(A)	72
Engine Model	kM186FA
Engine type	Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel
Bore × Stroke(mm)	86× 72
Displacement (L)	0.418
Rated Power KW	5.7/3000	6.3/3600
Fuel comsumption Rate(g. kw/h)	275.1	281.5
Compression Ratio	19: 1
Lubrication System	Pressure Splashed
Starting System	Electric Start with 30Ah MF battery
Fuel Type	0#(summer), -10#(winter), diesel
Lube Oil Brand	SAE10W30 (above CD Grade)
Lube Capacity (L)	1.65
Fuel Tank Capacity (L)	15
Continuous Running Time (hr)	9.5
Overall Dimension: LxWxH (mm)	955 x 560 x 780
Dry Weight (Kg)	170
Quantity in 20FT	72 Pcs
Optiomal Features:
ATS	Optional
Digital Panel	Optional
Remote control	Optional
We reserve the right to change specifications without notice
