5kw Open Type Diesel Generator

Name: 5kw Open Type Diesel Generator
Brand: Sumokama
SKU: 140761048
Availability: InStock

US$ 300 - 800 MOQ: 30 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Sumokama

Model Number:

KDE6500

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number KDE6500

Output Type AC Three Phase

Speed 3000/3600RPM

Frequency 50/60HZ

Rated Power 5KW

Rated Voltage 120/240

Specifications

Alternator with brush and automatic voltage regulator (AVR) provide stable output voltage and current .

Model	Silent Diesel Generator Set
	KDE3500LN		KDE5000LN		KDE6000LN
Alternator-Type	Revolving field type 2pole generator
Frequency (Hz)	50	60	50	60	50		60
Rated output(kW)	2.8	3.0	4.2	4.5	4.5		5.0
Voltage (V)	110,115,120,220,230,240,110/220,115/230,120/240
DC output	12.2 V-8.3A
Engine speed(r/min)	3000	3600	3000	3600	3000		3600
Power factor(% )	1.0
Excitation System	Controlled Constant Operation
D.C output V/A	12V/8.3A
Coupling Pattern	Straight Shaft Coupling
Engine Model	DY178FE		DY186FE		DY 186FAE
TYPE	Direct injection Vertical, 4cycle, air cooled diesel engine
Displacement (cc)	296		406			418
Rated Output(kw/rpm)	3.7	4.0	5.7	6.3	5.7		6.3
Max.Output(kw/rpm)	4.0	4.4	6.3	6.8	6.3		6.8
Starting system	Electric start
Governor system	Centrifugal weight system
Fuel tank capacity(L)	16
Lube oil capacity(L)	1.1		1.65
BorexStroke(mm)	78x62		86x70		86x72
Protection system	CX: Low oil, warning system/stop device
Dim LxWxH(mm)	850x520x730		920x520x730
N.W.(kg)	135		175
Noise level at 7m dBA	78
