T80-3 80hp Crawler Type Dozers

US$ 20,000 - 50,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Henan, China

Brand Name:

YTO

Model Number:

T80-3

Luoyang Mingyang Engineering Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Tianjin/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name YTO

Model Number T80-3

Condition New

Moving Type Crawler Bulldozer

Machine Weight 8600kg

Dimension(Long * Breadth * High) 4200x2480x2740mm

After-sales Service Provided Engineers available to service machinery overseas

T80-3 80hp Crawler Type Dozers

Main features:

1. The machine adopts the YTO LR4A3Z-22 surcharged diesel engine, with strong power, low noise and low specific fuel consumption.

2. Gearbox is 4F+2R mechanical gear shifting, applicable for various environments.

3. Integral trolley traveling construction adopting rigid chassis and semi-rigid hamger.

4. Advanced operation control system, fully hydraulic aided steering, with flexible and labor-saving operation.

5. Driver cab is welded with profile steel, with high strength, resistant against impact, and good protection performance.

6. The machine is flexible and of high operation efficiency and applicable for construction in narrow ground.

Technical specifications:

Model		T80-3
Total weight	kg	8600
Max towing force	KN	82
Engine model		LR4A3Z-22
Engine rated power	KW	70
Engine rated speed	r/min	2200
Fuel Consumption of the engine	g/kw.h	≤246
Engine max. torque	N.M	313.9
Forward I-IV gears	km/h	2.4~10.4
Reverse I-II gears	km/h	4.9~8.9
Max. slope angle	°	≥30
Caterpillar track board width	mm	400
Land pressure	Kpa	51
Overall length	mm	4200
Overall width	mm	2480
Overall height	mm	2740
Blade width	mm	2544
Blade height	mm	880
Blade max. lifting height	mm	784
Blade max. digging depth	mm	357
Cutting angle(adjustable)	°	55
Traction equipment/ Scarifier (optional)	Stationary type/ Three teeth
